2021-2022 Audi e-tron Energy Consumption Display Low TSB

Symptoms

Owners of 2021-2022 Audi e-tron models may notice that the "average long-term energy consumption displayed in the instrument cluster is implausibly low." This issue typically manifests after approximately 3,000 miles of driving.

If the long-term memory is reset, the energy consumption display will temporarily show correct values. However, the problem will recur once another 3,000 miles have been driven, leading to a consistently low reading for the Audi e-tron energy consumption low issue.

Diagnosis and Trigger Conditions

The root cause of the inaccurate display is a software malfunction within the instrument cluster. This software error causes the values shown to be incorrect, specifically impacting the average long-term energy consumption.

Repair Procedure Summary

To resolve the "Audi e-tron energy consumption low" problem, a software update for the Audi virtual cockpit is required. This update involves using an ODIS Tester and applying the optimized software.

Technicians will update the Audi Virtual Cockpit software using either an automated method via ODIS or a manual update if there are SVM code or server issues. The update process utilizes SVM code 17A040 and is detailed in TSB 2060523: 91 MIB3 Software Update Instructions. The entire update procedure, including the software update and SVM work, takes approximately 30-60 minutes.

Required Tools or Parts

To perform this software update, the following equipment is necessary:

• ODIS Tester: Used for diagnostic and programming functions.
• USB Flash Drive: Required for the software update. Specific SD Creator Part Numbers are:
  • For MY2021 vehicles: 4N0 906 961 AQ
  • For MY2022 vehicles: 4KE 906 961 A

Warranty Information

This Technical Service Bulletin (TSB 90 22 37 2065793/1) outlines the warranty claim procedures for addressing the Audi e-tron energy consumption low issue. The repair is covered under warranty for up to 48 months or 50,000 miles, whichever comes first. For Certified Pre-Owned (CPO) vehicles, the G10 claim type applies, requiring verification of ownership.

If your vehicle is outside of the warranty period, this Technical Service Bulletin serves as informational guidance. The damage code for this repair is 0039, and the service number is 9025. Labor operations for the software update, including checking for Diagnostic Trouble Codes (DTCs), are assigned code 0151 0000.

Important Warnings

Owners and technicians should be aware of specific requirements during the software update process:

• Key Placement: The vehicle key must be placed on the emergency key reader coil to start and remain there throughout the entire update procedure.
• Warranty Information: Please refer to the warranty information provided specifically within this TSB (90 22 37 2065793/1) and disregard any conflicting information found in TSB 2060523 regarding warranty claims.

This TSB 90 22 37 2065793/1 replaces the previously issued Pending Service Solution (PSS) TSB 2063789/1.

NHTSA ID: 10207101
