2022-2023 Audi MIL on DTC P240700 Evap Leak

Audi has released Technical Service Bulletin (TSB) 01 24 37 2066675/10 to address instances where the Malfunction Indicator Lamp (MIL) illuminates in certain 2022-2023 Audi models. This TSB specifically pertains to a condition where the Engine control module, -J623-, registers Diagnostic Trouble Code (DTC) P240700, related to the evaporative (Evap) leak detection pump circuit.

This bulletin, identified as revision 10, supersedes previous guidance, specifically Technical Service Bulletin Group 01 number 24-28 dated July 3, 2024. It provides important information for technicians and owners regarding this specific diagnostic fault.

Symptoms

Owners of affected Audi vehicles will observe the following symptom:

• "The MIL is illuminated."

This indicates that the vehicle's onboard diagnostic system has detected an issue requiring attention.

Fault Codes / DTCs

The primary diagnostic trouble code associated with this issue is:

Code	Description	Module
P240700	Evap emission control system leakage diagnosis pump current fluctuating.	Engine control module, -J623-

Diagnosis and Trigger Conditions

Technicians will find the DTC P240700 stored as "Passive/Static" in the Engine control module, -J623- (address word 001). For this TSB to apply, the event memory must not contain any other relevant entries alongside P240700.

Important Warnings and What Owners Should Know

Audi has provided critical guidance for this specific issue:

• No immediate repairs are necessary: A solution for the Evap leak detection pump circuit issue is currently under development and is expected to be available by the end of the 4th quarter of 2024. This timeline is subject to change.
• Do not replace components: Owners and technicians are advised, "Do not replace any components for this condition since it will not resolve the customer's concern." Replacing parts prematurely will not fix the underlying issue and may lead to unnecessary costs.
• Informational TSB: If your vehicle is outside of its warranty period, this Technical Service Bulletin is for informational purposes only.

What to Do if You Experience This Issue

If your 2022-2023 Audi displays the MIL with the Audi Q8 P240700 MIL fault, it is recommended to contact your authorized Audi dealership. While no immediate repair is available, the dealership can confirm the presence of DTC P240700 and create a Pending Service Solutions (PSS) record. This record helps Audi track the issue and ensures you are informed when a permanent solution becomes available. Do not attempt to replace parts related to the Evap system, as this will not resolve the Audi Q8 P240700 MIL condition.

Related Service Bulletins

For specific 2022 and 2023 Audi Q5 45, Q5 PHEV, Q7 2.0L, and 2022 Q3 vehicles, technicians should refer to TSB 2071770, titled "01 MIL on, DTC P240700 Leak Detection Pump Current Fluctuating." This indicates a related but distinct bulletin for certain models.

Warranty Information

Warranty claims related to this TSB must adhere to the Audi Warranty Policies and Procedures Manual. The details for claiming this specific condition are:

• Claim Type: Informational only (if vehicle is outside of warranty)
• Service Number: 2048
• Damage Code: 0040
• Diagnostic Time: GFF (0150 0010 or 0150 0060)
• Claim Comment: As per TSB 2066675/10

All parts and service references in this TSB (2066675) are subject to change and/or removal.
