2022 Audi MIL On DTC P240700 Evap Leak

Symptoms and Customer Observations

Owners of affected 2022 Audi vehicles equipped with a gasoline engine may observe the Malfunction Indicator Lamp (MIL) illuminated on their dashboard. This Audi MIL On DTC P240700 condition is the primary symptom reported by customers. The MIL, commonly known as the "Check Engine Light," indicates a detected fault in the vehicle's emissions system.

Diagnostic Trouble Code (DTC) P240700

When diagnosing the Audi MIL On DTC P240700 issue, technicians may find the following diagnostic trouble code (DTC) stored in the Engine control module, J623 (address word 001):

Code	Description	Module
P240700	Evap leak detection pump circuit	Engine control module, J623

This DTC may be stored as either Passive or Static. It's important to note that for this specific concern, the event memory must not contain any other relevant entries.

Important Warnings and Interim Guidance

Audi has issued specific guidance regarding this condition under Technical Service Bulletin 01 23 39 2066675/2. Owners and technicians should be aware of the following critical instructions:

• Do not replace any components for this condition. Audi explicitly states that replacing parts "will not resolve the customer's concern." This is because a permanent solution is still under development.
• A solution is expected to be available by the end of the 3rd quarter of 2023. However, this timeline is "subject to change."

Service Procedure for Dealerships

For dealerships encountering this issue, the current procedure outlined in the Technical Service Bulletin is informational and focuses on customer communication and record-keeping. Technicians are instructed to explain to the customer that no repairs are necessary at this point, as a solution is still pending. Instead, a Pending Service Solutions (PSS) record must be created. This record is generated through the PSS application, accessible via the Pending Service Solutions link in Access Audi or the Technical Assistance page in Elsa. This process helps Audi track the prevalence of the issue and prepare for the eventual release of a definitive fix.

Warranty Coverage Details

This issue, identified by Service Number 2048 and Damage Code 0040, may be covered under warranty. For new vehicles, coverage typically extends up to 48 months or 50,000 miles. For Audi Certified Pre-Owned (CPO) vehicles, specific G10 coverage may apply, requiring verification of ownership. If your vehicle falls outside of these warranty periods, this Technical Service Bulletin serves as informational guidance only. Diagnostic time for checking and clearing fault codes (GFF) is included in existing labor operations, with a maximum of 50 TU (Time Units) stated on the diagnostic protocol. Road tests, both prior to and after any service procedure, are not allotted any time units (0 TU). All warranty claims, submitted as per TSB 2066675/2, must adhere to the Audi Warranty Policies and Procedures Manual and are subject to review or audit.

Bulletin Revision History

This Technical Service Bulletin 01 23 39 2066675/2, dated January 27, 2023, is a revision of an earlier document. It supersedes Technical Service Bulletin Group 01 number 22-19, which was dated March 29, 2022. The revisions include an updated expected release date for the service solution and a revised header that incorporates additional affected models. The initial publication of this bulletin was on March 29, 2022.

Owner Action and Next Steps

If your 2022 Audi is displaying a MIL Light On and a diagnostic scan confirms the presence of DTC P240700, you should contact your authorized Audi dealer. While no immediate repair is necessary, the dealer can create a Pending Service Solutions (PSS) record. This record helps Audi track the prevalence of the issue and ensures that your vehicle is noted for the eventual solution. Do not attempt to replace any parts related to the Evap leak detection pump circuit, as this TSB explicitly states it will not resolve the problem. Stay in communication with your dealer for updates on when the permanent solution becomes available.

---

Source: NHTSA ID: 10230929
