2020-2021 Audi MIB3 Navigation Malfunction DTC B126CF0

Revision History

This Technical Service Bulletin (TSB) 91 21 69 2062115/2, issued on February 17, 2021, supersedes Group 91 TSB number 21-65 dated February 4, 2021. The revisions include updated service instructions for formatting the navigation database (NavDB) and updated information regarding the required USB tool.

Symptoms

Owners of 2020-2021 Audi models equipped with MIB3 navigation may experience the following issues:

• "The navigation system is permanently initializing."
• "The navigation map is corrupt or incomplete."

Fault Codes / DTCs

When these symptoms occur, technicians may find the following Diagnostic Trouble Code (DTC) stored in the vehicle's information electronics control module:

Code	Description	Module
B126CF0	Navigation system Navigation database malfunctioning	Information electronics control module, J794 (address word 005F)

Diagnosis / Trigger Conditions

This navigation system issue typically arises after an over-the-air navigation map update. An internal reset during this update can cause the navigation database within the MIB3 system to become corrupted. This corruption leads to the navigation system either permanently initializing or displaying a corrupt or incomplete map, often triggering the Audi navigation fault B126CF0.

Repair Procedure Summary

Audi Technical Service Bulletin 2062115/2 outlines a specific procedure for dealerships to resolve the corrupted navigation database issue. The process involves obtaining and installing a new MIB3 navigation database.

1. Database Acquisition: The technician contacts Audi's Technical Assistance Center (TAC) to receive a download link and detailed instructions for acquiring the current MIB3 navigation database. This ensures the latest and correct files are used for the update.
2. File Download: The necessary navigation database files are downloaded from the provided link to a PC's C drive. It is important to avoid using Internet Explorer for this download.
3. USB Preparation: A USB flash drive, 32GB or larger, must be formatted to FAT32. This step is critical, as the update will not proceed if the USB drive is formatted to any other file system. Formatting the drive will erase all existing data on it.
4. File Extraction to USB: Using a file compression utility like 7-Zip, the downloaded navigation files are extracted directly onto the root directory of the formatted USB drive. The files must not be placed within any subfolder on the USB drive. Figure 1 in the TSB shows an example of the extracted files, including P0516_MIB3_NA_Q320.MD5, P0516_MIB3_NA_Q320.SHA256, and P0516_MIB3_NA_Q320.SIZE.
5. Vehicle Software Update:
   • After the files are on the USB, the drive is safely ejected from the PC.
   • In the ODIS diagnostic system, the technician navigates to 005F Information Electronics >> Basic settings >> Formatting partitions of internal memory.
   • Under Parameters, Navigation data bank is selected, and the basic setting is run.
   • The USB drive is then inserted into the vehicle.
   • The technician accesses the MMI settings section: MMI settings >> system maintenance >> software update.
   • At this point, the software update should be available for installation if all prior steps were performed correctly.

Required Tools or Parts

To perform this repair, a USB Flash Drive of 32GB or larger is required. This item is locally sourced. Technicians may also refer to TSB 2037809, "91 MIB: MMI navigation map update 'How-to guide' - potential customer concerns," for additional guidance.

Important Notes for Technicians

• The USB drive MUST be formatted to FAT32; any other format will not work for the update.
• The extracted navigation files CANNOT be placed in a single folder on the USB drive; they must be copied directly to the root directory.

Warranty Information

This repair is covered under Audi's warranty program with the following details:

• Claim Type: 110 (up to 48 Months/50,000 Miles) or G10 for Certified Pre-Owned (CPO) vehicles (owner verification required).
• Service Number: 9196
• Damage Code: 0039
• Labor Operations:
  • Reinstall the Navigation Database: 9196 9999 (20 Time Units)
  • Diagnostic Time: GFF (0150 0000, maximum 15 Time Units as stated on the diagnostic protocol)
  • Road test prior to service procedure: No allowance (0 Time Units)
  • Road test after service procedure: No allowance (0 Time Units)
• Claim Comment: As per TSB # 2062115/2.

If the vehicle is outside of any applicable warranty, this Technical Service Bulletin serves as informational guidance only. All warranty claims must adhere to the Audi Warranty Policies and Procedures Manual and are subject to review and audit by Audi Warranty.

---

NHTSA ID: 10189033
