2025 Audi A5/Q5/S5/SQ5 Software Update 03.10.00/C

Audi has released Technical Service Bulletin (TSB) 2079690/6 to address a range of system optimizations and improvements for certain 2025 Audi A5, S5 (FU), A6 Sportback e-tron, S6 Sportback e-tron (GH), Q5, Q5 Sportback e-tron, SQ5, SQ5 Sportback e-tron (GU), Q6 e-tron, Q6 Sportback e-tron, SQ6 e-tron, and SQ6 Sportback e-tron (GF) vehicles. This TSB details the procedure for installing a combined software update, version 03.10.00/C (28.13.01) KD2, which aims to enhance the overall user experience and vehicle functionality.

This 2025 Audi A5 software update is comprehensive, targeting multiple vehicle systems. Owners experiencing issues with their digital key, navigation, or general vehicle connectivity should be aware of this important update.

Revision History

This Technical Service Bulletin has undergone several revisions to refine its content and scope:

• Revision 6: The header was revised to include market 4NA.
• Revision 5 (November 26, 2025): The service instructions were revised, including updated verbiage and additional adaptation instructions.
• Revision 4 (November 10, 2025): The header was updated with new PR codes, and the condition section was revised to include an updated model table.

What this TSB Addresses

This software update, identified as 03.10.00/C (28.13.01) KD2, resolves several complaints and introduces various optimizations. Owners of affected vehicles may notice improvements in the following areas after the 2025 Audi A5 software update:

• Display and User Settings: General optimizations to how information is displayed and how users interact with the system.
• Navigation System: Enhancements to depiction, route calculation, route guidance, and overall navigation performance.
• Connectivity: Optimizations for APN (Access Point Name), Bluetooth, radio, navigation, and eCall services.
• Operation: Improvements to the voice assistant and the navigation system's operational aspects.
• Traffic Sign Recognition: General optimization of recognition, addressing malfunctions and deactivation of assist systems.
• Driving Characteristics: Improvements related to moving off, hold function, and juddering.
• Warning Lamps: Avoidance of incorrect warning lamps appearing on the instrument cluster.
• Charging: Optimizations to charging times, application functionality, State of Charge (SOC) display, and resolution of charging difficulties.
• Mobile Key: Improvements to key detection and the keyless system.
• Child Presence Detection: Optimizations to avoid incorrect triggering of the child presence detection system.
• Digital Key Sharing: The update enables sharing of the digital key with up to 5 digital keys, including the main key.

Important Warnings and Owner Information

Audi has provided several critical notices within TSB 2079690/6 that owners and technicians must be aware of:

• Prerequisite Campaigns: All open field campaigns must have been performed on the vehicle in advance of this software update. Technicians are instructed to work through them according to their publication date.
• Physical Key Requirement: A physical key (remote control key) is mandatory to perform the software update. The digital key and digital key card cannot be used for this procedure.
• Digital Key Reset for Sharing (PR 2F1): For vehicles equipped with PR number 2F1, the digital key must be reset after the update to enable sharing with other people. If a digital key is already in use, resetting the key user will remove it, requiring it to be set up again.
• Mobile Data Deactivation: Owners should be informed that Mobile Data is turned off automatically after the software update and may need to be reactivated manually.
• Settings Readjustment: Various vehicle settings must be re-adjusted after the software update. A customer letter is attached to the TSB for technicians to print and provide to owners, detailing these necessary adjustments.
• High-Voltage Vehicles: For vehicles with high-voltage components, the high-voltage charging cable must be unplugged before the SVM code is entered to prevent the battery from charging during the update. Charging during the update can cause damage to high-voltage components.
• Bus Sleep Mode: The vehicle must be put into bus sleep mode before the function "SVM – Authorized Multiple Code Entry" is run. The update must be started directly after a bus sleep.
• Software Update Progress: During the software update, progress may not be displayed in the vehicle for the first 20 to 30 minutes. The display may switch on and off multiple times or remain dark for several minutes. A reliable indication of progress is only shown after this initial period. No actions, such as switching the ignition on/off or selecting a gear, should be performed on the vehicle during this time.
• Aborted Flashing: If flashing is aborted, error messages are shown or messages are shown in the instrument cluster during the software update. In such cases, technicians must refer to the separate TSB 2079692 00 Aid for TSB 2079690 (00 Combined software update 03.10.00/C (28.13.01) KD2).

Digital Key Functionality and Sharing

This TSB specifically addresses the digital key system, particularly for vehicles with PR number 2F1. To ensure proper functionality and sharing capabilities after the 2025 Audi A5 software update, a specific procedure must be followed.

Requirements for Digital Key Procedure

Before performing any digital key-related steps, ensure the following:

• A physical key (remote control key) is available.
• The key user's device is available.
• A key user has already been created for the vehicle.
• The vehicle has mobile reception, is online, and has a valid time signal (sufficient satellite reception).

Procedure Part 1 (Prior to Software Update)

1. The vehicle's ignition must be switched on using the physical key (remote control key).
2. If a digital key has been adapted previously, it must be deleted before the software update:
   • Open the "Digital key" menu option in the MMI.
   • Select the "Management" tab and then "Primary device management".
   • Select "Remove primary device". The physical key must be inside the vehicle.
   • Confirm that you want to remove the main device.

Note that digital keys will be deactivated on the main device, and the customer will receive a push notification from the myAudi app. This notification does not affect the subsequent steps.

Procedure Part 2 (Following Software Update)

After the software update, the digital key must be set up again, deleted again, and then set up again. This process initiates the backend procedure that enables digital key sharing.

1. Open the "Digital key" menu option in the MMI.
2. Select the "Management" tab and then "Primary device management".
3. Select "Remove primary device". The physical key must be inside the vehicle.
4. Confirm that you want to remove the main device.

After a short waiting period, the customer will be able to add the digital key in the myAudi app again, enabling the sharing function.

If it is not possible to set up the digital key during the workshop procedure, technicians are instructed to delete and set it up again after the software update. Customers should be provided with instructions for setting up the digital key, which involves the same steps as Procedure Part 2, ensuring a physical key is available, the key user's device is available, a key user is created, and the vehicle has mobile reception, is online, and has a valid time signal.

Service Procedure Overview

The total duration for the combined software update, including preliminary and follow-up work, is approximately 3.5 hours. There are different procedures for PPE (Premium Platform Electric) and PPC (Premium Platform Combustion) models.

Prerequisites for Flashing

Before initiating the software update, several conditions must be met:

• The driver's door must remain open throughout the flashing procedure. Diagnostic interface cables should not be routed through the window, as window regulators will be initialized later.
• Activate privacy mode (mobile data off).
• Switch off background lighting in the HMI to prevent negative interference.
• Only one vehicle key should be inside the vehicle. For Audi Q6 e-tron and A6 e-tron (PPE), the key must be placed on the hazard warning lights switch. For Audi A5, Q5, and A6 (PPC), it must be on the reader coil.
• Before entering each code, verify that the current date/time is displayed in the vehicle. If not, move the vehicle to a location with GPS reception or set the date and time manually. Failure to do so will prevent or abort the update.
• No additional work may be performed on the vehicle during the update.
• Firewall settings corresponding to the latest ODIS version release notes at Elsa2Go>>Service References>>Vehicle Diagnostics must always apply.

Preparing the Vehicle for Flashing

1. Put the vehicle in bus sleep mode for 5 minutes.
2. Ensure the vehicle is locked (all doors, trunk, and hood closed).
3. It is critical to allow the vehicle to sleep between retry attempts after a failure.
4. Connect a battery charger unit according to
