2022-2025 Audi A3/S3/RS 3 Magnetic Field Too Low DTCs

Owners of 2022-2025 Audi A3, S3, and RS 3 models may encounter dashboard warnings such as "Multiple messages/Pre sense fault message in the cluster" along with specific diagnostic trouble codes (DTCs). These issues, including the Audi S3 magnetic field too low problem, are detailed in Audi Technical Service Bulletin (TSB) 2072549/3, which supersedes TSB 24-42 dated May 7, 2024.

This TSB outlines a software update procedure to correct the underlying cause of these fault messages and DTCs, ensuring proper vehicle operation and preventing unnecessary parts replacement.

Symptoms

Owners may observe the following symptoms:

• "Multiple messages/Pre sense fault message in the cluster."
• Diagnostic Trouble Codes (DTCs) related to magnetic field readings or databus errors stored in control units.

Fault Codes / DTCs

Workshop findings indicate specific DTCs stored in the vehicle's control units:

Code	Description	Module
C101AF1	"magnetic field too low"	ABS control unit J104
C101BF1	"magnetic field too low"	ABS control unit J104
C101CF1	"magnetic field too low"	ABS control unit J104
C101DF1	"magnetic field too low"	ABS control unit J104
U112300	"Databus error value received; Databus implausible message"	Distance Regulation control unit J428
U112200	"Databus error value received; Databus implausible message"	Distance Regulation control unit J428

Diagnosis / Trigger Conditions

The presence of any of the listed DTCs in the ABS control unit J104 or Distance Regulation control unit J428, often accompanied by Pre sense fault messages, indicates the need for this service action. The issue stems from outdated software versions within these control units.

Important Warnings

Audi explicitly states:

• "Do not replace speed sensors! Parts replacement does not solve the issue. Claims for replaced parts will be subject to review."

Before proceeding with any software updates, technicians must ensure that the speed sensors are free of debris, oil residues, grease, or dirt.

Repair Procedure Summary

The primary solution for the Audi S3 magnetic field too low issue and related DTCs is a software update using the Software Version Management (SVM) system. This process follows the instructions in TSB 2011732 for SVM operating instructions.

The specific steps depend on the hardware version of the ABS control unit J104:

For Vehicles with Hardware Version 13 in ABS Control Unit J104 (Except RS3)

1. Check the current software version of the brake control unit. If it is lower than 133, perform SVM Codes 03A033A followed by 03A033B. These updates will bring the ABS control unit J104 to software version 134.
2. After the initial update, run SVM Code 03A037.
3. If the vehicle already has software version 133 or 134, only run SVM Code 03A037.
4. After the software update, proceed with parking brake basic settings.

For Vehicles with All Other Hardware Versions in ABS Control Unit J104 (or RS3)

1. Delete all DTCs stored in the ABS control unit J104 (address word 0003) and Distance Regulation control unit J428 (address word 0013).
2. Perform a short road test.
3. No additional work is necessary, and the DTCs should not return.

Warranty Information

This service action is covered under warranty for vehicles up to 48 months or 50,000 miles. For Audi Certified Pre-Owned (CPO) vehicles, coverage is provided under claim type G10, requiring owner verification. If the vehicle is outside of any warranty, this Technical Service Bulletin serves as informational guidance only.

• Service Number: 4545
• Damage Code: 0039
• Diagnostic Time: Software Update (0151 0010, 0151 0060)
• Road Test Allowance: 0 TU prior to service, 10 TU after service.

All warranty claims must comply with the Audi Warranty Policies and Procedures Manual and are subject to review or audit by Audi Warranty.

Production Solution

Audi implemented improved software in production vehicles starting from April 2024 to prevent these issues in newer models.

NHTSA ID: 11002966
