2023-2024 Audi Parking Brake Malfunction TSB

Symptoms of the Audi Q8 Parking Brake Malfunction

Owners of affected 2023-2024 Audi vehicles may observe a specific message on their instrument cluster: "Parking brake malfunction warning in the cluster." This warning indicates an issue with the vehicle's electro-mechanical parking brake system. While the warning itself is clear, the underlying cause might not be immediately apparent to the driver.

Associated Fault Codes (DTCs)

When the "Parking brake malfunction warning in the cluster" appears, technicians may find specific Diagnostic Trouble Codes (DTCs) stored in the ABS control unit. These codes provide more detail about the nature of the detected fault:

Code	Description
C100C07	Electro-mechanical parking brake button mechanical malfunction
C100C29	Electro-mechanical parking brake button implausible signal

These DTCs, C100C07 and C100C29, point directly to an issue with the electro-mechanical parking brake button's operation or the signal it sends to the ABS control unit.

Understanding the Cause

According to Audi TSB 46 23 45 2070679/1, these DTCs are typically stored when the parking brake switch is pressed and held for a short duration. This can occur inadvertently, for example, if the driver accidentally presses the parking brake switch while interacting with the MMI system. Another common cause is a foreign object becoming lodged in the gap around the parking brake switch, causing it to get stuck in a pressed position.

Important Warning for Owners and Technicians

It is crucial to understand that if the diagnostic trouble code (DTC) was triggered by the parking brake switch being accidentally held down or getting stuck due to a foreign object, replacing parts will not fix the problem. This warning, highlighted in the TSB, prevents unnecessary part replacements and ensures the actual root cause is addressed. This specific guidance helps avoid costly and ineffective repairs.

Diagnosis and Repair Guidance

For technicians, the TSB advises inquiring with the customer about their usage of the parking brake switch. Understanding if the switch might have been accidentally pressed or if a foreign object could have caused it to stick is key to proper diagnosis. If these conditions are identified as the cause of the Audi Q8 parking brake malfunction, then physical replacement of the parking brake button or related components is not the correct solution.

What Owners Should Do

If you experience an "Audi Q8 parking brake malfunction" warning in your 2023-2024 Audi, first check the area around your electro-mechanical parking brake button for any foreign objects that might be causing it to stick. Be mindful of how you interact with the button, especially when operating other controls like the MMI system, to avoid accidental prolonged presses. If the warning persists after checking for obstructions and being careful with button usage, it is recommended to visit an authorized Audi service center. They can perform a diagnostic scan to confirm the DTCs and investigate the specific circumstances leading to the warning, ensuring the appropriate action is taken without unnecessary part replacement.

Warranty Information

This Technical Service Bulletin 46 23 45 2070679/1 is provided for informational purposes only. It is not applicable to any Audi warranty, meaning that diagnosis and resolution of this issue may not be covered under standard warranty terms if the cause is determined to be external (e.g., foreign object) or user-induced (e.g., accidental prolonged press).

---

Source: NHTSA ID: 10238235, TSB 46 23 45 2070679/1, June 20, 2023.
