2021-2023 Audi Clicking Noise from Wheel Bearing TSB

Owners of various 2021-2023 Audi models may experience an Audi clicking noise wheel bearing when driving, especially during low-speed maneuvers or parking. This issue is addressed by Audi Technical Service Bulletin (TSB) 40 22 37 2024318/11, which provides a specific repair method for technicians.

Symptoms

If your Audi is affected, you will typically notice a:

• "Clicking or clacking noise when maneuvering or parking."

This noise can originate from either the front left or front right wheel bearing.

Technical Background

According to Audi, the Audi clicking noise wheel bearing is caused by microscopic movements that occur between the wheel bearing itself and the wheel bearing housing. These minute shifts can create the audible clicking or clacking sound that owners report.

Important Warnings

Owners should be aware of a critical warranty detail outlined in TSB 40 22 37 2024318/11:

• "Tip: Wheel bearings replaced for this concern will not be reimbursed under warranty."

This means that if a wheel bearing is replaced instead of performing the specified paste application procedure, the repair may not be covered under warranty. The TSB is informational only for vehicles outside of warranty.

Repair Procedure Summary

The repair procedure for the Audi clicking noise wheel bearing involves two main steps:

1. Preparation: Technicians must first remove any corrosion and dirt from the affected wheel bearing and its housing.
2. Paste Application: A thin coat of assembly paste, part number G 052109A2, is then applied to the wheel bearing housing. Approximately 0.21 ounces (6 grams) of paste is used, ensuring it is not applied to the threads.

This TSB, identified as 40 22 37 2024318/11, supersedes an earlier bulletin, Group 40 number 21-31, dated December 23, 2021, due to updated parts and tools information.

Required Parts and Tools

To perform this repair, the following parts are required:

• G 052109A2: Assembly paste (Quantity: 0.1)
• See ETKA: Fasteners, bolts, nuts, and screws as needed per the repair manual.

Warranty Information

Warranty claims for this repair fall under specific categories:

• Claim Type 110: Covers vehicles up to 48 months or 50,000 miles.
• Claim Type G10: Applies to Certified Pre-Owned (CPO) vehicles, requiring owner verification.

The Service Number associated with this bulletin is 4057, and the Damage Code is 0010. All warranty claims must adhere to the Audi Warranty Policies and Procedures Manual.

Revision History

This Technical Service Bulletin has undergone several revisions:

• Revision 11: Revised Parts and Tools (Updated Quantity).
• Revision 10 (12/09/2021): Revised header (Added Model Year).
• Revision 9 (05/13/2020): Revised header (Added Models and Model Years) and Revised Warranty (Updated Labor Operation TU).

---

Source: NHTSA ID: 10209453
