2022-2024 Audi e-tron eCall Fault DTC B200000

Owners of various 2022-2024 Audi models equipped with ConBox High may encounter an "Emergency call function: malfunction! Function unavailable. Please contact service" message in the instrument cluster, accompanied by a red eCall LED. This condition is typically linked to a diagnostic trouble code (DTC) B200000, indicating a control module fault in the Emergency Call Module and Communication Unit (J949).

Technical Service Bulletin (TSB) 91 24 23 2059528/10, issued on June 28, 2024, addresses this specific concern. This bulletin supersedes an earlier version, TSB Group 91 number 24-09 dated May 7, 2024, with updated information including added model years and revised repair procedures.

Symptoms

Owners will typically observe the following indications of an Audi eCall fault B200000:

• A warning message displayed in the instrument cluster stating: "Emergency call function: malfunction! Function unavailable. Please contact service".
• The eCall LED (light-emitting diode) illuminates red.

Fault Codes / DTCs

When scanned, the Emergency Call Module and Communication Unit (ConBox), identified as J949 (address word 0075), will log the following diagnostic trouble code:

Code	Description
B200000	Ctrl. Module Faulty

Diagnosis and Trigger Conditions

This Audi eCall fault B200000 is primarily a software issue. The DTC B200000 is logged by the system without a valid underlying reason, indicating a need for optimized software versions for the Emergency Call Module and Communication Unit (ConBox). The TSB notes that the DTC setting conditions will be improved with these new software versions.

Repair Procedure Summary

The repair for the Audi eCall fault B200000 involves a two-part process to address the software anomaly. Technicians must ensure they are using the most current ODIS version, with a minimum requirement of ODIS > 2024.04.00.

Part 1: Diagnostic Check and DTC Erase

1. The technician will perform the program "J949 – Control Module for Emergency Call Module and Communication Unit, check control module" from the ODIS test plan. This program is automatically added when DTC B200000 is logged.
2. Alternatively, the function can be found in ODIS under Self-test >> Diagnostic capable systems >> 0075 – Control Module for Emergency Call Module and Communication Unit -J949- >> 0075 – Electrical components.
3. After running the program, the technician will verify if the DTC has been erased and if the "Emergency call function: malfunction!" message has disappeared from the instrument cluster. If the message persists, Part 2 of the repair procedure is necessary.

Part 2: Software Update (if needed)

For 2020 and 2021 model year vehicles, a comprehensive software package is available. This package is designed to fix several complaints, including the eCall fault. Details on distributing and using this software package are described in other service documents:

• Cluster 35 service update TSB 2067021 (for MY 2020 vehicles).
• Recall 91DZ (for MY 2021 vehicles).

Important Warnings

Owners should be aware that if their vehicle is outside of any applicable warranty, this Technical Service Bulletin is informational only, meaning the repair may not be covered free of charge.

Warranty Information

The repair outlined in TSB 91 24 23 2059528/10 is covered under warranty for vehicles up to 48 months or 50,000 miles. For Certified Pre-Owned (CPO) vehicles, the G10 claim type applies, requiring owner verification. All warranty claims must adhere to the Audi Warranty Policies and Procedures Manual.

• Service Number: 9145
• Damage Code: 0039
• Labor Operations:
  • GFF 01 50 00 10 (See SRT with associated operations)
  • GFF 01 50 00 60 (Labor according to diagnostic log)
• Claim Comment: As per TSB 2059528/10

---

Source: NHTSA ID: 11003022
