2023-2024 Audi Phone Box Wireless Charging Not Working TSB

Audi has issued Technical Service Bulletin (TSB) 91 23 07 2064681/3 to address customer concerns regarding the Audi Phone Box wireless charging system in 2023-2024 Audi models. This bulletin supersedes TSB Group 91 number 23-79 dated March 8, 2023, and provides guidance on diagnosing and understanding why a mobile device may not charge wirelessly.

Symptoms

Owners of affected Audi vehicles may observe the following issues with their Audi Phone Box wireless charging:

• The mobile device sometimes cannot be charged wirelessly.
• The phone gets very hot while charging and charging is canceled and/or the phone goes into thermal protection mode.
• The phone is not charged and the following message is shown on the MMI: "The device cannot be charged as there is another object in the charging cradle."
• The phone does not start charging after it has been placed in the charging cradle.

These issues can occur even if the mobile device supports wireless charging or if a charging cover is used.

Diagnosis / Trigger Conditions

The Audi Phone Box wireless charging feature can be affected by several factors. To diagnose the issue, technicians and owners should check the following:

• Ensure wireless charging is activated in the MMI settings.
• Verify that there are no objects other than the mobile phone in the charging cradle.
• If the phone has a case or back cover, check if it charges without the case/cover.
• Confirm the phone is centered in the charging cradle, as position significantly affects charging characteristics. The cradle uses three charging coils, but only one is active at a time, leading to more energy loss and heat if the device is misaligned.
• If the device becomes very hot during wireless charging, especially when the battery is low, check if the concern can still be reproduced when the battery level is above 80%.
• Intensive app use during wireless charging can also cause the device to overheat. Check if the concern persists when all apps are closed, including CarPlay or AndroidAuto.
• Charging can take up to 60 seconds to start.
• Test the charger with a different phone to rule out device-specific issues.

Important Warnings

• USB Connection Advisory: If intensive use of the mobile device is required while charging, Audi recommends using a USB connection instead of the Audi Phone Box wireless charging system.
• Apple iPhone MagSafe Incompatibility: For Apple iPhone generations 12, 13, and 14, MagSafe charging technology is not fully compatible with the industry-standard Qi system used in the vehicle. This incompatibility can lead to higher power losses, increased heat generation, temporary restrictions in phone functionality, and the phone entering thermal protection mode or shutting off. Audi advises that this behavior is normal and caused by the phone, not the vehicle. Do not replace parts as that will not resolve the customer complaint.

Repair Procedure Summary

This TSB is primarily informational and does not outline a specific repair procedure. Instead, it guides technicians through a series of diagnostic checks to identify the root cause of the Audi Phone Box wireless charging issue. If the concerns persist after performing the recommended checks, technicians should continue the repair process using Guided Fault Finding.

Owner Action

If you are experiencing issues with your 2023-2024 Audi's Audi Phone Box wireless charging, first try the diagnostic steps outlined above, such as checking phone placement, removing cases, and ensuring no other objects are in the cradle. If the problem persists, especially after considering the MagSafe compatibility for newer iPhones, it is recommended to contact your authorized Audi dealer for further diagnosis. This TSB is informational and not applicable to any Audi warranty.

NHTSA ID: 10238289
