2021 Audi A6/A7 Selector Lever Fault TSB 2074733/2

Audi Technical Service Bulletin (TSB) 2074733/2, superseding previous bulletin 24-10, addresses a common issue in certain 2021 Audi A6, A7, S6, S7, RS 6 Avant, RS 7, and A7 e quattro models. Owners may experience a "Selector lever fault" message in the instrument cluster and an inability to select gears. This TSB provides a software update solution for the affected vehicles.

This bulletin was initially published on July 31, 2024, and revised on August 27, 2024, to include additional model years and adjust the SVM table.

Symptoms

Owners of affected Audi vehicles may observe the following issues:

• A "Selector lever fault" message displayed in the instrument cluster.
• The vehicle's gears cannot be selected.

Fault Codes / DTCs

When diagnosing the issue, technicians may find specific Diagnostic Trouble Codes (DTCs) stored in the vehicle's control units. These codes indicate a problem with the gear selector lever system.

DTC Code	Diagnostic Address	Description	Symptom Code
P17E600	0081	Selector lever position sensor implausible signal	2003
P091900	0081	Selector lever error	5031
P18CB00	0081	Button for parking lock implausible signal	3003
P085D00	0002 (TCM -J217-)	Selector lever malfunction	22351

Diagnosis / Trigger Conditions

The underlying cause for the "Audi A6 selector lever fault" and related DTCs is a voltage evaluation issue that leads to an event memory entry. This indicates an internal problem with how the vehicle's system monitors the gear selector lever's position and function.

Important Warnings for Owners

Owners should be aware of several critical points regarding this service action:

• High-Voltage Vehicle Precaution: For vehicles equipped with high-voltage components, the high-voltage charging cable MUST be unplugged before the SVM code is entered for the software update. Failure to do so can cause damage to the high-voltage components due to charging the battery during the update.
• No Reimbursement for Replaced Parts: Claims for replaced parts will not be reimbursed under this Technical Service Bulletin. The repair focuses solely on a software update.
• Third-Party Modifications: If non-genuine components or modifications have been carried out on the vehicle by third parties (e.g., tuning), neither Audi AG nor the dealership will accept liability for any damage caused by the software update or by failing to perform it. Technicians are instructed to ask customers about such modifications and note them on the job order.

Repair Procedure Summary

The resolution for the "Audi A6 selector lever fault" involves updating the software of the 0081 control unit, which is the Gear Selector Lever -J587-. This is performed using an SVM (Software Version Management) action code.

Technicians are instructed to follow the detailed instructions provided in TSB 2011732, titled "00 Software Version Management (SVM), operating instructions." The process involves updating the -J587- (0081) control unit to the latest software version. After the software update, various control units in the vehicle must be reconfigured to ensure proper communication and function.

Software Version Details

Below are the specific old and new software part numbers for the affected models:

Model	Diagnostic Address	Old Software Part Number	Old Software Version	New Software Part Number (or higher)
2019 A6/A7	0081	4K1713041H	0050	4K1713041M
2020 A6/A7	0081	4K1713041H	0051	4K1713041M
2021 A6/A7	0081	4K1713041K		4K1713041M
S6/RS 6		4K1713041J		4K1713041L
S7/RS 7		4K1713041J		4K1713041L

Warranty Information

This Technical Service Bulletin is informational only if the vehicle is outside of its warranty period. For in-warranty repairs, the following codes apply:

• Service Number: 3785
• Damage Code: 0039
• Labor Operations: Software Update
• Claim Comment: As per TSB 2074733/2

All warranty claims must adhere to the Audi Warranty Policies and Procedures Manual and are subject to review by Audi Warranty.

NHTSA Source Citation

NHTSA ID: 11007306
