2024-2025 Audi MMI & Emergency Call Software Update TSB

Why This Matters

Owners of certain 2024-2025 Audi models may experience issues with their Multi Media Interface (MMI) system or encounter an "Emergency call fault" message displayed in the instrument cluster. These problems stem from underlying software issues that can affect various MMI functions and the critical emergency call system. Addressing an Audi MMI emergency call fault is important for maintaining vehicle functionality and safety features.

Symptoms You Might Notice

If your vehicle is affected, you might observe:

• Problems with various MMI functions, impacting infotainment, navigation, and connectivity.
• The specific message "Emergency call fault" appearing in your instrument cluster.

These symptoms indicate that the vehicle's diagnostic address 5F, which controls the information electronics, may be running one of the affected software versions: 4014, 4026, 4318, or 4404.

Important Warnings and What Owners Should Know

Audi has issued several critical advisories regarding this software update:

• Do not perform Guided Fault Finding test plans: For diagnostic entries in diagnostic address 0075 that are resolved by this software update, the Guided Fault Finding test plans should not be carried out and cannot be invoiced.
• Specific software version requirement: The update for the Android control unit (diagnostic address 078E) must only be performed if its current software version is below 0621.
• USB stick handling: During the update, "Please make certain to leave the USB stick inserted. The correct time to remove the USB stick is described further down." Once instructed, "Now please remove the USB stick."
• Prohibited media: You "must not use an SD card with an adapter USB stick" for creating the update media.
• Warranty billing: Time stamps are not required for billing under warranty when carrying out this TSB. This allows technicians to work on other vehicles during the lengthy update process.
• No replacement of components: The TSB implies that the issue is software-related, and diagnostic entries related to diagnostic address 0075 will be repaired by the software update, preventing unnecessary component replacements.

Affected Software and Control Units

The core of this issue lies in software problems affecting the MIB3 infotainment system and the AED (Automatic Emergency Call Device) control unit. The TSB 2079904/2 specifically targets vehicles with the following software versions in diagnostic address 5F:

• 4014
• 4026
• 4318
• 4404

The update aims to bring the Android control unit (diagnostic address 078E) to software version 0621.

Repair Procedure Summary

The resolution for the Audi MMI emergency call fault involves a manual software update performed by an authorized Audi technician. This process includes:

1. Preparation: The technician will prepare the vehicle by parking it and ensuring the 12V battery is charged. Required USB-C sticks with the correct update media must be prepared.
2. AED Control Unit Update (078E):
   • If the Android control unit (078E) is not already at software version 0621, it will be updated via the MMI's red menu.
   • A USB update medium is inserted into the USB connection.
   • The technician navigates the MMI to select "Update" and the USB source, then starts the update for all control units shown.
   • After successful completion, the MMI will restart.
   • The system is restarted again by holding the volume control for 10 seconds.
3. SVM Code Entry for Emergency Call Module (0075) and Information Electronics (005F):
   • The technician uses the "SVM - Authorized Multiple Code Entry" function in "Flash" mode with the ODIS diagnostic software.
   • A specific SVM code chain must be entered exactly: 078EA001,DUCDTCPR0075MLB,FLIGHTON0075MLB,ZGDOIP,CL3BPA001US,TGU1MDMVB,CL3BPA002US,FLIGHTOFF0075MLB. This can be scanned via QR code or copied/pasted.
   • The test program will guide the technician to insert the USB medium and automatically run the update for the emergency call module (0075) and information electronics (005F).
   • If the procedure is interrupted, it must be repeated from step 2.
4. Post-Update Checks:
   • The vehicle is put into bus sleep mode, then the ignition is switched back on, and the MMI is started.
   • The emergency call LED in the roof module is checked to ensure it lights up green. If not, reference TSB 2079652 "Emergency call LED in roof module not lit up in green."
   • The diagnostic session is ended, and the diagnostic log is sent online.

Required Tools and Parts

To perform this software update, Audi technicians will require:

• ODIS Diagnostic Software: The tester used must have the latest ODIS update, which includes the new test program for software updates.
• USB-C Sticks: Multiple USB-C sticks are required for the update media.
  • For the AED control unit update media: Part number 8W0906961DQ.
  • For the MIB3 update media, depending on the current software version:
    • For MIB3 SW versions 4014, 4026, 4404: Part number 8W0906961GC.
    • For MIB3 SW version 4318: Part number 8W0906961GG.
• Important Note: Do not use an SD card with an adapter USB stick.

Warranty Information

This Technical Service Bulletin (TSB 2079904/2) outlines specific procedures for warranty claims. If the vehicle is outside of warranty, the TSB is for informational purposes only. For in-warranty repairs, the following service numbers should be used with damage code 0041:

• 9145: For complaints related to emergency call function or online services (valid for A4, A5, and Q5 models).
• 9196: For complaints about MMI functions.

Time stamps are not required for billing under warranty, allowing technicians flexibility during the update process.

Related Technical Service Bulletins

This TSB references other important documents:

• TSB 2060523 91 MIB3: Software Update Instructions: Provides general information on USB-C sticks for MIB3 software updates.
• TSB 2079652 Emergency call LED in roof module not lit up in green: This bulletin should be referenced if the emergency call LED does not turn green after the update.

---

Source: NHTSA ID: 11031019
