2021-2024 Audi Active Lane Assist Malfunction TSB

Audi has released Technical Service Bulletin (TSB) 96 24 92 2061932/7 to address instances where owners of certain 2021-2024 Audi vehicles experience malfunction messages related to Active Lane Assist or Traffic Jam Assist. This TSB, which supersedes previous bulletin 96 23-87 dated October 16, 2023, specifically targets situations where the diagnostic trouble code (DTC) U112300 is stored in one of two control modules.

This bulletin, revised on February 20, 2024, with its latest update being Revision 7, provides comprehensive guidance for diagnosing and resolving the underlying issue. Earlier revisions, such as Revision 6 (October 16, 2023) and Revision 5 (September 28, 2023), focused on updating frequency counters, models, PR code filters, condition requirements, service procedures, and warranty information.

Symptoms

Owners may notice one of the following malfunction indications displayed in the instrument cluster:

• "Audi Active Lane Assist: malfunction!"
• "Traffic Jam Assist: malfunction!"

These messages indicate a problem with the driver assistance systems that rely on the steering wheel's ability to detect driver input.

Fault Codes / DTCs

When these symptoms occur, workshop findings typically show one or more of the following DTCs stored in the vehicle's control modules:

Code	Symptom Code	Description	Module	Address Word
U112300	1123220	Databus error value received (active/static)	Front camera, R242	00A5
U112300	1123220	Databus error value received (passive/sporadic, frequency counter >= 5)	Front camera, R242	00A5
U112300	2153	Databus error value received (active/static)	Distance regulation control module, J428	0013
U112300	2153	Databus error value received (passive/sporadic, frequency counter >= 5)	Distance regulation control module, J428	0013

Diagnosis

These Audi vehicles are equipped with a capacitive steering wheel. This steering wheel features touch sensors designed to detect if the driver's hands are on the wheel. This system ensures driver attention when using driver assist features like Active Lane Assist and Traffic Jam Assist.

To diagnose the root cause of the "Audi Active Lane Assist malfunction U112300" or "Traffic Jam Assist malfunction U112300" messages, technicians should read the measured value data from the Data Bus On Board Diagnostic Interface (Gateway) - J533 (address word 0019). Specifically, they should check the status of IDE12609 - Steering wheel touch recognition, status. If a fault is indicated for this measured value, it confirms an issue with the capacitive steering wheel.

Repair Procedure Summary

The primary repair for this issue, once diagnosed, involves replacing the capacitive steering wheel. The replacement must be performed according to the detailed instructions provided in the Audi repair manual. This ensures the new steering wheel is correctly installed and calibrated, restoring the functionality of the driver assistance systems.

Required Tools or Parts

For the repair, the following parts may be required:

• Steering Wheel: If required, the specific part number should be determined using ETKA.
• Fasteners, Bolts, Nuts, and Screws: As needed per the repair manual, also to be sourced via ETKA.

Always consult with your Audi Parts Department and ETKA for the latest information and parts bulletins to ensure correct part identification and availability.

Warranty Information

Warranty claims for this issue fall under Claim Type 110 for vehicles up to 48 months or 50,000 miles. For Certified Pre-Owned (CPO) vehicles, Claim Type G10 applies, requiring owner verification. The Service Number is 4810, and the Damage Code is 0040. Labor operations include 'Steering wheel remove + reinstall' (code 4810 1900), with associated operations detailed in the Service Repair Time (SRT) guide. Diagnostic time is GFF (0150 0000), with a maximum of 50 Technical Units (TU).

Road tests before and after the service procedure are allocated zero allowance. All warranty claims must adhere to the Audi Warranty Policies and Procedures Manual and are subject to review or audit by Audi Warranty. The claim comment should reference TSB 2061932/7.

Important Warnings

If your vehicle is outside of its warranty period, this Technical Service Bulletin is for informational purposes only. Owners of out-of-warranty vehicles will be responsible for the cost of diagnosis and repair.

Owner Action

If you are experiencing the "Audi Active Lane Assist malfunction U112300" or "Traffic Jam Assist malfunction U112300" messages in your 2021-2024 Audi, it is recommended to schedule an appointment with an authorized Audi service center. They can perform the necessary diagnostic checks and replace the capacitive steering wheel if it is found to be faulty, ensuring your driver assistance systems function correctly.

NHTSA ID: 10250577
