2023-2024 Alfa Romeo Tonale / Dodge Hornet EPS Warning Light

This Mopar Warranty Operations Newsletter, Volume 10, Issue 6, provides crucial information for technicians and owners regarding several vehicle issues. Key topics include troubleshooting the Electric Power Steering (EPS) system in 2023-2024 Alfa Romeo Tonale and Dodge Hornet models, addressing "Auto Emergency Braking (AEB) Unavailable - Service Required" messages in 2022-2023 Jeep Grand Cherokee vehicles, and explaining why radios may shut off due to hot displays in 2022 D2/DT/DJ models.

EPS Warning Light and DTC C0529-00

Owners of 2023-2024 Alfa Romeo Tonale (GC) and Dodge Hornet (GG) vehicles may encounter an EPS warning light illuminated on the instrument panel. This is often accompanied by ESC (Electronic Stability Control) and ADAS (Advanced Driver-Assistance Systems) warning lights. This condition indicates a potential issue with the electric power steering system.

Symptoms

Drivers will notice the <EPS warning light> on the instrument panel. This will appear alongside the ESC and ADAS warning lights, signaling a system malfunction.

Fault Codes / DTCs

The primary diagnostic trouble code associated with this issue is C0529-00. When this DTC is active in the Electric Steering Control Unit (EPS), it can also trigger active DTCs and warning lights in other Electronic Control Units (ECUs), including:

• PCM (Powertrain Control Module)
• HCP (Hybrid Control Processor)
• ABS (Anti-lock Braking System)
• BCM (Body Control Module)
• IPC (Instrument Panel Cluster)
• PAM (Parking Assist Module)
• ETM (Engine Transmission Module)
• HALF (Headlight Aiming and Leveling Function)
• ACC (Adaptive Cruise Control)

Diagnosis / Trigger Conditions

The EPS warning light and associated DTC C0529-00 can be triggered by several conditions:

• Battery disconnection
• Replacement of the EPS unit
• Low battery or low voltage conditions
• Disconnection of the EPS power supply

If DTC C0529-00 is active, measurements from column torque, steering wheel angle, and accelerometer sensors may provide implausible values. These values should be disregarded while the DTC C0529-00 is active.

Repair Procedure Summary

The resolution for the Alfa Romeo Tonale EPS warning and DTC C0529-00 involves a power steering re-initialization procedure. This can be performed either without a diagnostic tool (as described in the Owner's Manual) or with one.

Manual Re-initialization (without diagnostic tool)

1. Move the ignition to the ENGINE position without pressing the brake pedal.
2. Press the brake pedal and move the ignition to the START position.
3. Fully turn the steering wheel to the right and hold for 2-3 seconds until a kickback is felt.
4. Fully turn the steering wheel to the left and hold for 2-3 seconds until a kickback is felt.
5. Return the steering wheel to the central position.
6. Switch off the engine by moving the ignition to the STOP position. The EPS warning light should turn off.

Diagnostic Tool Procedure (if C0529-00 is active)

1. Disconnect and reconnect both battery posts.
2. Connect a diagnostic tool to the Electric Guide Control Unit (EPS).
3. Check for DTC C0529-00. If active, perform the power steering re-initialization procedure as described above. If not active, a thorough troubleshooting must be performed.
4. If DTC C0529-00 remains active after two manual re-initialization attempts:
   • Connect the diagnostic tool to the EPS control unit and launch the "Steering angle calibration" procedure.
   • After this, connect the diagnostic tool to the ABS control unit and launch the "Steering angle offset zeroing" procedure.

Important Notes

Carefully follow all instructions displayed during the diagnostic procedures. Do not proceed to subsequent steps until the current step is fully completed. After completion, perform a KEY/OFF cycle, wait for the parking brake warning light to turn off on both the panel and button, then perform a KEY/ON cycle.

Auto Emergency Braking (AEB) Unavailable Message

Owners of 2022-2023 Jeep Grand Cherokee (WL) vehicles may see a pop-up message on the cluster stating, "Auto Emergency Braking (AEB) Unavailable - Service Required". This issue is often linked to recent changes made in the radio's SETTINGS menu.

Diagnosis / Trigger Conditions

If this message appears after a customer has adjusted radio settings, it is a known issue with no current fix. Technicians should review Star Online (SOL) Case Number S238A000038 for more information.

Radio Shutting Off Due to Hot Display

For 2022 D2/DT/DJ model year vehicles, customers might report a message stating "Screen is Hot. Display is Shutting down to cool down", followed by the radio display shutting off. This behavior is considered normal operation.

Owner Action

If the radio shuts off due to overheating, owners should reduce the HVAC settings to 80°F AUTO or lower for approximately 15 minutes. This allows the radio to return to normal operating temperature.

Important Warnings

It is critical to Do Not replace the radio for this condition, as it is operating as per specification. Technicians should review Star Online (SOL) Case Number S238A000014 Rev. A for further details.

---

Source: NHTSA ID 11003055
