2022-2025 Audi Q7 Common Issues: DTCs, Leaks, and Noises

Audi has released an internal analysis list from February 4, 2024, outlining several common issues affecting various 2022-2025 Audi models, including the Audi Q7. This document provides initial guidance for technicians on how to address these concerns, ranging from diagnostic trouble codes (DTCs) to mechanical noises and fluid leaks.

Important Guidance for Technicians

Before attempting any repair for the Audi Q7 common issues or other listed problems, technicians are instructed to contact the Audi Helpline for further instruction. It's important to note that as of June 7, 2024, worksheets will no longer be a standard practice and will only be required if specifically mentioned in the topic details of the communication.

Common Issues and Symptoms

This analysis list covers several distinct problems, each with specific diagnostic and preliminary repair steps.

Leaking Timing Chain Cover Gasket

• Affected Models: 2022-2025 Audi Q5 models equipped with the DPVA engine.
• Symptoms: Visible fluid leaks originating from the timing chain cover gasket area.
• Diagnosis: Technicians must capture clear photos and video footage of the active leak. This documentation is crucial before contacting the Technical Assistance Center (TAC) for further guidance.

ECM DTC P060600 "ECM/PCM Processor" Fault

• Affected Models: 2022-2025 Audi A4, A5, Q5, and Q7 models with 2.0L engines only.
• Symptoms: The presence of Diagnostic Trouble Code (DTC) P060600, indicating an issue with the Engine Control Module (ECM) or Powertrain Control Module (PCM) processor.
• Diagnosis: If the DTC P060600 is present, technicians should attempt to clear the fault. After clearing, a test drive of at least 20 miles is recommended to determine if the fault can be reproduced. Further instruction requires contacting TAC.

Airbag Light On for DTC B12251B

• Affected Models: 2022-2025 Audi Q7 models.
• Symptoms: The airbag warning light illuminates on the instrument cluster, accompanied by DTC B12251B.
• Diagnosis: Technicians are advised to contact TAC directly for further instructions regarding this airbag system fault.

Noise from Engine Belt Tensioner

• Affected Models: 2024-2025 Audi A4, A5, Q5, and Q7 models.
• Symptoms: Audible noise emanating from the engine belt tensioner.
• Diagnosis: The first step is to verify that the belt tensioner is indeed the source of the noise. Technicians should refer to TSB 2070568 for detailed procedures and use a PICO tool to take basic acoustic measurements in the engine bay area. The PICO readings must then be attached to the service ticket when contacting TAC for further instruction.

Creaking Noise from Front Instrument Panel Area

• Affected Models: 2022-2025 Audi A8 and S8 models.
• Symptoms: A creaking noise originating from the front instrument panel area, often linked to loose front suspension strut tower brace bolts. This is another of the Audi Q7 common issues (though specific to A8/S8 for this particular symptom).
• Repair Procedure Summary:
  1. Documentation: Photo and video documentation is required, specifically highlighting which bolts are loose. This should include both distance shots showing the location and close-up photos of the loose bolts.
  2. Replacement: Replace the strut tower brace and all associated bolts.
  3. Bolt Marking: Before removal, technicians should either mark each bolt to determine its original position or secure them to the brace in their original locations using tape or wire.
  4. TAC Case Submission: A TAC case must be submitted with a Worksheet titled "Creaking noise in front instrument panel area as in TSB 2066526."
  5. Parts Retention: All replaced parts must be retained for return to WPRC (Warranty Parts Return Center).
  6. Customer Concern Description: Provide a brief description of the customer's concern and the conditions under which the noises are elicited.
  7. PID Usage: Use PID 5069 during the repair process.

What Owners Should Do

If you experience any of these symptoms or warning lights in your 2022-2025 Audi Q7, A4, A5, Q5, A8, or S8, it is recommended to schedule an appointment with an authorized Audi service center. Technicians will utilize this internal guidance and contact the Audi Helpline as necessary to diagnose and resolve the issue. Ensure to describe the symptoms accurately to assist with the diagnostic process.

NHTSA ID: 11015720
