2021-2023 Tesla Model Y Interior Camera Replacement

Introduction

Tesla has released Service Bulletin SB-24-17-005 R1, a campaign bulletin addressing a specific condition related to the interior camera in certain 2021-2023 Model S, Model X, and Model Y vehicles. This bulletin, issued on January 16, 2025, supersedes a previous version, SB-24-17-005, dated September 20, 2024. The update includes information for the EMEA region and parts for right-hand drive vehicles. This document provides technical diagnosis and repair procedures for technicians, particularly relevant for the Tesla Model Y interior camera system.

What is the issue?

The core issue identified in Service Bulletin SB-24-17-005 R1 concerns the interior camera in affected vehicles. Specifically, the interior camera requires replacement to mitigate reduced driver attentiveness detection performance when operating in low-light conditions. This means that the system designed to monitor driver attentiveness, including the Tesla Model Y interior camera, may not function optimally under certain lighting conditions, potentially impacting features that rely on this detection.

What is the fix?

The prescribed correction for this issue is the replacement of the interior camera. This procedure is identified by correction code S012417005. The estimated time for this repair varies slightly by model: 0.12 hours for Model S and Model X, and 0.06 hours for Model Y. This ensures that the new interior camera will provide improved driver attentiveness detection performance, especially in low-light environments.

Required Parts

To perform the interior camera replacement, technicians will need specific parts. The general parts required include:

• 1011416-00-B: SCR,M3-0.5X8,PH,TRX-T10,STL,ZNC,PATCH (Quantity 2)

Additionally, specific interior camera parts are required depending on the vehicle model and drive configuration:

• For Model S and X:
  • 1588124-S0-J: INTERIOR CAMERA, IR (LHD) (Quantity 1)
• For Left-Hand Drive Model Y: One of the following:
  • 1588124-80-I: INTERIOR CAMERA, IR (LHD) (Quantity 1)
  • 1588124-S0-I: INTERIOR CAMERA, IR (LHD) (Quantity 1)
• For Right-Hand Drive Model Y: One of the following:
  • 1588124-81-1: INTERIOR CAMERA, IR (RHD) (Quantity 1)
  • 1588124-S1-1: INTERIOR CAMERA, IR (RHD) (Quantity 1)

Tesla advises that these part numbers were current at the time of publication and recommends checking the Parts Catalog for the latest revisions.

Repair Procedure Summary

The repair procedure for replacing the interior camera involves following Service Manual procedure 17241602. This detailed procedure is applicable to Model S, Model X, and Model Y vehicles. Technicians are instructed to consult the service manual for comprehensive, step-by-step instructions to ensure proper installation and calibration of the new interior camera. This ensures the Tesla Model Y interior camera functions correctly after the service.

Important Notes for Owners

Tesla explicitly states that Service Bulletin SB-24-17-005 R1 addresses a non-safety-related condition. This means that while the issue impacts the performance of the driver attentiveness detection system, it is not considered a direct safety hazard requiring an immediate recall. Tesla is not notifying consumers for this type of bulletin. Owners of affected 2021-2023 Tesla Model Y, Model S, or Model X vehicles experiencing this condition should contact a Tesla service center to schedule the interior camera replacement. This service can potentially be performed via mobile service where permitted.

---

Source: NHTSA ID: 11013482
