2025 BMW X5/X6/X7 KSG Supply Line Delivery Stop SIB 24 02 25

BMW has issued Service Information Bulletin SIB 24 02 25 (Revision 1), dated January 8, 2026, which supersedes SI B24 02 25 dated December 2025. This bulletin details a delivery stop for certain 2025 BMW X5, X6, and X7 models due to a potential issue with the crankshaft-driven starter generator (KSG) supply line.

The core problem is a threaded connection at the 48V power electronics (EME 48) that may not have been properly secured during manufacturing. If this connection loosens further, it could result in a no-start condition or a complete vehicle breakdown.

Important Warnings

BMW AG initiated a Delivery Stop effective November 25, 2025, for affected Model Year 2026 BMW vehicles produced on November 19, 2025. This means that vehicles cannot be delivered to customers until this update is completed. If a vehicle is already in the workshop for another reason, this repair must be performed prior to delivery or other work completion.

Symptoms

The primary symptom of this issue is the potential for a vehicle to experience a "no-start" condition. In more severe cases, the vehicle could suffer a complete breakdown while in operation due to the loosening connection at the 48V power electronics.

Diagnosis / Trigger Conditions

The root cause is a threaded connection at the EME 48 (48V power electronics) that was not adequately secured during the vehicle's production. There are no specific fault codes mentioned in the bulletin; the issue is mechanical in nature, leading to a loss of power supply to the crankshaft-driven starter generator.

Repair Procedure Summary

To address the 2025 BMW X5 KSG supply line issue, technicians will perform the following steps:

1. Preparation: Disconnect the negative battery terminal and disable the 48V system. This involves following Repair Instruction 61 20 900, which details the process for disconnecting and connecting the battery ground lead.
2. Access: Remove the rear underbody protection to gain access to the affected components. This step refers to Repair Instruction 51 47 491, which covers removing, refitting, or replacing the rear engine undercover.
3. Component Removal: Loosen specific screws and remove the heat shield to expose the power electronics (MHEV) area.
4. Screw Plug Removal: Remove the screw plug for the power electronics (MHEV).
5. Retighten Connection: Retighten the threaded connection of the MHEV supply line to a torque of 19 Nm.
6. Screw Plug Replacement: Replace the screw plug for the power electronics (MHEV), torquing it to 35 Nm.
7. Reassembly: Install the heat shield and retaining plate on the tunnel, tightening them to 2.5 Nm. Reinstall the rear underbody protection as per Repair Instruction 51 47 491.
8. Final Steps: Reconnect the negative battery cable, including the 48V vehicle electrical system, following Repair Instruction 61 20 900.

Required Tools or Parts

The following part is required for this repair:

• Part Number: 24 14 8 645 681
• Description: Power electronics screw plug
• Quantity: 1

Additional materials like fluids, lubricants, one-time use screws, nuts, and seals may also be required based on ISTA repair instructions or the Electronic Parts Catalog.

Claim Information

Reimbursement for this action will be processed using the applicable work package information. The Repair Code for this procedure is 0012640600, which covers the reworking of the threaded connection of the KSG supply line for G05, G06, and G07 models. Special flat rate labor operation codes, such as 00 79 598 or 00 79 097, are used for claiming the labor allowance, which varies by model (e.g., 6-9 FRU depending on the vehicle).

---

Source: NHTSA ID: 11027760
