2025 BMW CID Black After MFD Replacement SIB 65 20 25

Symptoms

Owners may notice that after the Multifunctional Display (MFD) has been replaced, the Central Information Display (CID) appears black. Despite the black screen, the CID's backlight will still be illuminated, and the touch function will register an audible sound when interacted with. This specific issue is referred to as "CID IS BLACK AFTER REPLACING THE MULTIFUNCTIONAL DISPLAY" in BMW's documentation.

Cause

The root cause of the BMW X5 CID black screen issue is a change in the supplier for the replacement Multifunctional Display (MFD). Original MFDs may have been manufactured by Continental, while replacement units are now supplied by InnoLux. These different hardware manufacturers use distinct video coding, leading to an incompatibility that results in the CID remaining black after installation if the correct coding is not applied.

Repair Procedure Summary

To resolve the BMW X5 CID black screen problem, technicians must perform a specific conversion and coding procedure. This involves adding the special equipment code SA 8WM – "Control D" to the vehicle's order via a conversion process, which then triggers the proper video coding for the InnoLux replacement CID.

Here are the general steps involved:

1. Software Verification: Ensure that the dealership's diagnostic software, ISTA, is at version 4.55.1x (released August 21, 2025) or higher.
2. MFD Installation: Install the new InnoLux Multifunctional Display (MFD) into the vehicle.
3. Conversion in ISTA: Using ISTA, navigate through the menu to select the conversion option labeled "Replacement of display cluster in the case of replacement parts". This is found under Vehicle Management > Vehicle Modification > Conversion.
4. Perform Conversion: Execute the conversion procedure within ISTA. This process will automatically reprogram and code all programmable control modules that do not have the latest software, ensuring compatibility with the new MFD.
5. Vehicle Test: After programming is complete, a vehicle test should be performed. Any fault memory should be deleted.

Important Warnings

• Battery Charger: Always connect a BMW-approved battery charger/power supply (such as SI B04 23 10) to the vehicle during the programming and coding process to maintain stable voltage.
• Control Module Failures: If any control modules fail during the reprogramming procedure, additional repair work may be required. Technicians should claim these consequential repairs using the appropriate repair codes and labor operations.

Required Tools or Parts

• Diagnostic Software: ISTA 4.55.1x or higher.
• Power Supply: A BMW-approved battery charger/power supply.
• Multifunctional Display (MFD): The specific part number for the Multifunctional Display (LHD) should be referenced in ETK/AIR based on the vehicle's VIN/Chassis number.

Claim Information and Labor Operations

For repairs covered under the BMW New Vehicle Limited Warranty or BMW Certified Pre-Owned Program, the following information is relevant for claiming the repair:

• Repair Code: 6552001200 for "Onboard monitor / control display / central information display (CID), front (including trim cover) Permanent failure". If another repair code applies, the conversion procedure will be claimed under "Replacement of display cluster in the case of replacement parts".
• Labor Operations: Various labor operations are associated with this repair, including removing and installing the instrument cluster (65 50 210 or 84 10 850), performing vehicle tests (00 00 006 or 00 00 556), supporting voltage (61 21 528), diagnosis worktime (61 00 006* or 00 58 500*), and the specific worktime for the conversion "Replacement of display cluster in the case of replacement parts" (84 99 000 – 1 FRU). Programming and encoding control units (61 00 730) is also included.

This procedure ensures that the BMW X5 CID black screen issue is correctly addressed, restoring full functionality to the display.

What Owners Should Do

If you have recently had your Multifunctional Display (MFD) replaced in your 2025 BMW and are now experiencing a black Central Information Display (CID), contact your authorized BMW dealership. Inform them about the symptoms you are experiencing and mention BMW Service Information Bulletin (SIB) 65 20 25. The dealership technicians are equipped with the necessary diagnostic tools and procedures to perform the required conversion and coding to resolve the issue.

---

Source: NHTSA ID: 11022855
