2024 BMW X5, X6, X7, XM Seat Massage Inoperative SIB 52 09 25

Symptoms

Owners of 2024 BMW X5, X6, X7, and XM vehicles may experience the seat lumbar system's "Massage" function not working. This can affect either the driver's or passenger's seat, or both, if the 04T7 Massage function option code is present.

Fault Codes / DTCs

This issue, which causes the BMW X5 seat massage inoperative condition, can be accompanied by several diagnostic trouble codes (DTCs) related to the seat modules. These codes indicate problems with control unit coding, encoding, or installation location not being taught.

Code	Description	Module
025908	SPNMVR: Control unit is not coded	Seat pneumatics module front right (SPNM_VR)
02590B	SPNMVR: Control unit is not encoded for the vehicle	Seat pneumatics module front right (SPNM_VR)
806927	SPNMVR: Installation location not taught in	Seat pneumatics module front right (SPNM_VR)
025308	SPNMVL: Control unit is not coded	Seat pneumatics module front left (SPNM_VL)
02530B	SPNMVL: Control unit is not encoded for the vehicle	Seat pneumatics module front left (SPNM_VL)
8067A7	SPNMVL: Installation location not taught in	Seat pneumatics module front left (SPNM_VL)
80301E	No seat adjustment because of engine start conditions	Seat Module Driver (FAS SMFA)
802C1E	No seat adjustment because of engine start conditions	Seat Module Passenger (BFS SMBF)
802E1E	No seat adjustment because of engine start conditions	Seat Module Driver's Side Rear (FAH SMFAH)
802A1E	No seat adjustment because of engine start conditions	Seat Module Passenger Side Rear (BFH SMBFH)

Diagnosis / Trigger Conditions

These fault codes and the resulting BMW X5 seat massage inoperative condition typically occur after the vehicle undergoes programming or experiences a loss of power. The underlying cause is that the seat modules require re-initialization. This situation can affect either the driver's or passenger's seat, or both, if their respective modules are not properly configured.

Important Warnings

BMW notes that if a seat is not properly initialized, other seemingly unrelated functions, such as seat heating, may also be disabled. This highlights the importance of correct initialization for full seat functionality.

Repair Procedure Summary

To correct the BMW X5 seat massage inoperative issue, the seat modules must be re-initialized. This procedure is performed using the BMW diagnostic system, ISTA.

1. Access Initialization Procedure: Technicians should navigate to "SERVICE FUNCTIONS" within ISTA, then select "BODY," followed by "SEATS," and finally "SEAT ADJUSTMENT STANDARDIZATION." The correct ABL test plan for the specific affected seat must then be chosen.
2. Proper Seat Initialization: For successful initialization, the seats must be fully assembled with their leather covers. The initialization process has a time limit; if the seat leather/foam is not in place, the motor can move the seat frame past its intended stopping point, causing the seat to fail initialization. Additionally, if equipped, second-row headrests must be in the fully down position to prevent interference with the first-row seats during the initialization process. The initialization must be performed on all four seat modules if the vehicle is equipped with them.

This Service Information Bulletin SIB 52 09 25 also notes that these networked seats are described in more detail in Service Bulletin B52 23 19, which provides comprehensive information on all relevant seat bulletins.

Warranty Information

This Service Information Bulletin (SIB) provides technical, diagnosis, and repair-related information. Repairs addressing the inoperative seat massage function, when due to a verified defect in materials or workmanship, are covered under the terms of the BMW New Vehicle Limited Warranty for Passenger Cars and Light Trucks.

However, damage or issues caused by outside influences or prior improper repairs are not covered. When submitting a claim, technicians should use the Repair Code "Refer to AIR / SIB (non-Recall / non-Service Action)" and the Labor Operation "61 00 828" for "Initialize a system." The labor allowance is "As applicable." For detailed procedures on documenting and claiming diagnosis and repair work time, technicians should refer to SI B01 01 20 or B01 07 20.

Owner Action

If you experience the seat massage function not working in your 2024 BMW X5, X6, X7, or XM, it is recommended to schedule an appointment with an authorized BMW service center. The repair involves a diagnostic and re-initialization procedure covered under BMW's New Vehicle Limited Warranty for defects in materials or workmanship.

NHTSA ID: 11020931
