2022 BMW iX Delivery Stop: Steering Gear Replacement

BMW AG has issued Service Information Bulletin (SIB) 32 03 24, a Delivery Stop, for certain 2022 BMW iX (i20) Sports Activity Vehicles. This bulletin, which is Revision 1, replaces the earlier SI B32 03 24 dated August 2024. The Delivery Stop became effective on August 2, 2024, and applies to vehicles produced between October 14, 2021, and November 21, 2022. The primary concern is a faulty Electric Power Steering (EPS) gear, necessitating a 2022 BMW iX steering gear replacement.

Important Warnings for Owners and Technicians

BMW has issued critical directives regarding vehicles affected by this Delivery Stop:

• "Do not deliver to a customer, a New, Certified Pre-Owned or Used vehicle subject to a Delivery Stop, until the vehicle is repaired. Do not use or sell replacement equipment/parts subject to a Delivery Stop."

Additionally, working on the High-Voltage (HV) systems in these Battery Electric Vehicles (BEV) requires specialized training and precautions:

• Only properly trained personnel who have passed all applicable HV Technical Training Courses should perform repairs involving high-voltage components. Unqualified work can lead to severe injury or vehicle damage. Technicians must observe safety instructions found in Repair Instruction 61 00... "Observe safety instructions when handling electric vehicles".
• Before disconnecting or removing any HV component, the HV system must be disabled and secured using the HV Service Disconnect Switch and lockout by a properly trained HV technician.
• Specific HV certifications, such as ST2324 High Voltage Drivetrain Systems, ST1824 Alternative Drive Part 1, ST2205 Generation 5 High-voltage class, ST2006 – SP44 HV Battery, and ST2325 for High Voltage Battery Systems, are required depending on the vehicle generation and specific HV component being serviced.

Symptoms

Owners of affected 2022 BMW iX vehicles may notice specific warnings and changes in steering behavior. The primary symptom is a check control (CC) message appearing on the instrument cluster stating: "Steering behavior. Drive moderately. Have it checked by the nearest service partner."

In addition to this warning message, drivers will experience a noticeable reduction in power steering assistance, particularly when parking. This indicates a problem with the Electric Power Steering (EPS) system, making the 2022 BMW iX steering gear replacement necessary.

Cause

The root cause of this issue is identified as a faulty capacitor installed within the Electric Power Steering (EPS) gear. This component defect affects the proper functioning of the power steering system.

Repair Procedure Summary

The correction for this issue involves replacing the Electric Power Steering (EPS) gear. The procedure is detailed in REP 32 13 752, titled "Replace electrical steering box (EPS)". After the physical replacement, the vehicle's control units require programming and encoding to ensure proper operation of the new EPS unit. This programming and encoding may be performed in conjunction with other open campaigns or as a standalone procedure. The repair code for this action is 0032630300.

Additional labor operations may be required, including commissioning of the electromechanical steering gear (32 13 905), kinematics diagnosis system wheel alignment (32 00 595), adjusting toe-in on the front axle (32 00 601), and additional work for integral active steering (32 00 650) if applicable. These steps ensure the steering system is correctly calibrated and aligned after the replacement.

Required Parts

To perform the 2022 BMW iX steering gear replacement, the following parts are required:

• 32 10 5 B35 7F4: Steering gear, electric (Quantity: 1)
• 07 11 9 905 400: Hex bolt with washer (M6x25-ZNNIV SI) (Quantity: 1)
• 07 14 6 898 283: Hex bolt (12x1.5x70 ZNS3) (Quantity: 4)
• 32 30 6 778 609: Torx bolt (M8x33) (Quantity: 1)
• 31 30 6 865 951: Torx screw with collar (M12x1.75x50) (Quantity: 4)
• 32 13 6 751 292: Hose clamp (D= 67.8 – 71.0) (Quantity: 1)
• 33 30 6 787 062: Combination nut (M14x1.5-10ZNNIV)[forced round - 5] (Quantity: 2)
• 37 10 6 789 678: Hex nut with flange (M12x1.5-10-ZNS3)[forced round 10] (Quantity: 2)
• 31 11 6 899 302: Multi-purpose bolt (10x45 ZNS3) (Quantity: 14)
• 61 27 9 487 465: Screw (12x1.5x100 10.9) (Quantity: 4)
• 83 23 8 849 305: Lubricating grease FB-1 (100 g) (Sublet as needed)

Owner Action

If you own a 2022 BMW iX produced between October 14, 2021, and November 21, 2022, it is crucial to ensure this Delivery Stop repair has been completed. Vehicles subject to a Delivery Stop cannot be delivered to customers until the necessary repairs are performed. If you have not yet taken delivery or suspect your vehicle may be affected, contact your authorized BMW dealer immediately to verify its status and schedule the required 2022 BMW iX steering gear replacement.

---

Source: NHTSA ID 11006727
