2022 BMW i4 Combined Charging Unit Delivery Stop

Important Warnings for Owners and Technicians

BMW has issued critical advisories regarding this issue and the necessary repairs:

• Delivery Stop: "Do not deliver to a customer, a New, Certified Pre-Owned or Used vehicle subject to a Delivery Stop, until the vehicle is repaired. Do not use or sell replacement equipment/parts subject to a Delivery Stop." This means affected vehicles cannot be sold or delivered until the Combined Charging Unit (CCU) is replaced.
• High-Voltage System Safety: Working on High-Voltage (HV) systems requires specialized training. "Only properly trained personnel, who passed all applicable HV Technical Training Courses, should perform repairs which require disconnecting, or removal of High Voltage battery components on any Hybrid or Electric Vehicle." Unqualified persons performing such work risk severe injury or damage to the vehicle. Additional safety information is found in Repair Instruction 61 00...
• HV System Disablement: Before any HV component removal, the HV system must be disabled and secured by a properly trained technician with a minimum HV Qualification level. Once disabled, a "Blitz" - lightning bolt icon displayed in instrument cluster will appear.

The Combined Charging Unit (CCU) Manufacturing Defect

BMW has identified a manufacturing defect affecting the Combined Charging Unit (CCU) in certain 2022 BMW i4 Gran Coupe vehicles. This issue is detailed in Service Information Bulletin SI B61 24 22, which is Revision 3 and replaces an earlier bulletin dated January 2, 2023. The defect necessitates a repair before affected vehicles can be delivered to customers.

Potential Symptoms

While the bulletin primarily describes a manufacturing defect, owners might eventually notice issues related to charging or the vehicle's high-voltage system. Technicians will observe a "Blitz" - lightning bolt icon displayed in instrument cluster once the high-voltage system is disabled for repair.

Repair Procedure Summary

The primary correction for this issue involves replacing the Combined Charging Unit (CCU). The repair procedure, referenced as REP 61 42 501, includes the following steps:

1. CCU Replacement: The defective Combined Charging Unit (CCU) must be replaced.
2. Programming and Encoding: After replacement, the vehicle's control units require programming and encoding to ensure compatibility and proper function with the new CCU. This process also updates any vehicle control modules to the latest software I-level.
3. Vehicle Test: A comprehensive vehicle test is performed to confirm the successful repair and proper operation of all systems.

This repair must be performed by a qualified technician, especially given the high-voltage nature of the components involved. The defect code associated with this repair is 0061160700, labeled as "G26 BEV Replace Combined Charging Unit (CCU)".

Required Parts

The following parts are required for the Combined Charging Unit (CCU) replacement:

• Combined Charging Unit (CCU): Part Number 61 44 5A73E23 (Quantity: 1)
• Hexagon Bolt: Part Number 12 90 9884545 (Quantity: 4)

Replaced parts are subject to BMW NA's retention policy and may need to be held for potential return.

Owner Action

If you own a 2022 BMW i4 Gran Coupe that falls within the affected production dates (July 5, 2022 – July 28, 2022), or if you are awaiting delivery of such a vehicle, it is crucial to ensure this repair has been completed. BMW dealers are instructed not to deliver any affected vehicle until the 2022 BMW i4 Combined Charging Unit has been replaced and the necessary programming performed.

Contact your authorized BMW dealer to verify if your vehicle is subject to this delivery stop and to schedule the necessary repair. This repair will be covered under warranty.

---

Source: NHTSA ID: 10249029
