2024 BMW 5 Series / 7 Series Fuel Pump Delivery Stop

Important Warnings for Owners

BMW has issued Service Information Bulletin SIB 16 02 24 as a "DELIVERY STOP" for affected vehicles. This means that the repair must be performed on all affected vehicles before they are delivered to customers. If a customer has already taken delivery, the procedure should be performed the next time the vehicle is in the shop, provided the campaigns have a remedy available status. Otherwise, the vehicle may be released.

Owners should also be aware that this Service Action repair qualifies for an Alternative Mobility Solution (AMS). This means that owners may be eligible for expense reimbursement related to mobility during the repair process. Refer to SI B01 29 16 for additional information regarding AMS.

Symptoms

Owners of affected 2024 BMW 5 Series (G60) and 7 Series (G70) vehicles might experience several issues related to fuel delivery. These can include insufficient fuel flow due to a restriction in the low-pressure fuel line. This lack of adequate fuel supply, even for a short period, could potentially lead to preliminary damage to the high-pressure fuel pump.

In the event of a fault, drivers may notice a power reduction from the engine. Another observable symptom is "jerking" motions while driving, indicating an inconsistent fuel supply to the engine. If you experience any of these symptoms, your vehicle may be affected by the 2024 BMW 5 Series fuel pump delivery stop.

Cause

The root cause of these fuel delivery issues is a manufacturing defect in the flange lid of the fuel supply unit. Specifically, the flange lid has a reduced cross-section where the fuel feed line connects. This design flaw restricts the flow of fuel, leading to the symptoms described.

Repair Procedure Summary

The repair outlined in BMW Service Information Bulletin SIB 16 02 24 involves replacing two key components of the fuel system. Technicians will replace both the in-tank delivery unit and the high-pressure fuel pump.

This procedure follows specific BMW repair instructions. For the supply unit, technicians will refer to Repair Instruction 16 14 090, which details the removal and installation/replacement process. For the high-pressure pump, Repair Instruction 13 51 017 will guide the removal and installation. The repair also includes draining sufficient fuel for access and reinsertion of components.

Required Parts

To address the 2024 BMW 5 Series fuel pump delivery stop, specific parts are required depending on the vehicle model. The following parts are listed for the G60 (5 Series) and G70 (7 Series) models:

For G60 (5 Series):

• Supply unit: 16 11 5 A2A C81
• O-ring: 16 11 7 476 100
• High-pressure pump: 13 51 7 934 496
• High-pressure line: 13 53 8 489 570
• Torx socket with washer: 13 51 7 632 572 (Quantity 2)
• Profile seal: 11 12 9 847 198

For G70 (7 Series):

• Supply unit: 16 11 5 A06 486
• O-ring: 16 11 7 476 100
• High-pressure pump: 13 51 7 934 496
• Torx screw with washer: 51 71 1 696 656 (Quantity 2)
• Torx socket with washer: 13 51 7 632 572 (Quantity 2)
• Profile seal: 11 12 9 847 198
• Hexagon screw with washer: 07 11 9 907 857 (Quantity 2)
• Hexagon bolt: 07 14 7 483 888 (Quantity 6)

Owner Action

If you own a 2024 BMW 5 Series (G60) or 7 Series (G70) vehicle, especially if you have not yet taken delivery, it is important to contact your authorized BMW dealer. They can check if your vehicle is affected by Service Information Bulletin SIB 16 02 24. This repair will be performed free of charge under the terms of the service bulletin.

If you have already taken delivery and experience symptoms such as power reduction or "jerking" motions while driving, schedule an appointment with your dealer. The repair code for this action is 0016870200.

---

NHTSA ID: 11006722
