2022 Audi e-tron GT / RS e-tron GT HUD Navigation Not Displayed

Symptoms

Owners of 2022 Audi e-tron GT and RS e-tron GT vehicles equipped with a Head-Up Display (HUD) may notice that "No navigation map or directions are displayed on the heads-up display (HUD)". While the navigation information is missing, all other information on the HUD, such as speed or warning indicators, is displayed correctly. This specific issue affects the Audi e-tron GT HUD navigation display.

Technical Background

According to TSB 90 22 63 2067174/1, the root cause of the missing navigation display in the HUD is a software-related malfunction. This issue does not affect the functionality of other HUD elements, only the navigation map and directions. This bulletin supersedes the previous Pending Service Solution (PSS) TSB 2065815, which also addressed the PSS 90 Head-up display: Navigation directions are not displayed.

Important Warnings for Technicians and Owners

This software update involves working with high-voltage components. To prevent potential damage, the high-voltage cable must be removed before entering the SVM code on vehicles with high-voltage components. Charging the high-voltage battery during a software update can cause damage to these components. Technicians are also advised to always use DoIP (Diagnostic over Internet Protocol) when flashing control modules via ODIS in supported vehicles. DoIP can be activated by navigating to Administration >> General >> GFF Process >> DoIP communication >> Only allow DoIP communication. This setting will automatically reset after the diagnostic session concludes. A red LED on the VAS 6154(A) indicates if DoIP is active.

Repair Procedure Summary

The repair for the missing Audi e-tron GT HUD navigation involves updating the software for the Head-Up Display (HUD), which is addressed at diagnostic address 0082. The process requires following all instructions detailed in TSB 2011732, which covers 00 Software Version Management (SVM) operating instructions. The update is performed using a specific SVM action code.

Required Software/Part Numbers

The software update for the HUD utilizes SVM code 82A003. This update applies to vehicles with the following old software part numbers and versions, bringing them to a newer version (0105 or higher):

Model	Old Software Part Number	Old Software Version	New Software Part Number	New Software Version	SVM Code Input
e-tron GT	4J3919617	0037	4J3919617	0105	82A003
		0101
	4J3919618	0102	4J3919618	0105
		0104

Warranty Information

This repair is covered under warranty for up to 48 months or 50,000 miles, whichever comes first, under claim type 110. For Certified Pre-Owned (CPO) vehicles, the claim type is G10, and owner verification is required. If your vehicle is outside of its warranty period, this Technical Service Bulletin 90 22 63 2067174/1 serves as informational guidance only. The service number for this procedure is 9091, with a damage code of 0039. Labor operations for the software update (0151 0000) have a maximum time allowance of 150 TU. Diagnostic and road test times are not separately compensated.

Owner Action

If you own a 2022 Audi e-tron GT or RS e-tron GT and are experiencing the issue where "No navigation map or directions are displayed on the heads-up display (HUD)", you should contact your authorized Audi dealership. Inform them about the issue and mention Technical Service Bulletin 90 22 63 2067174/1. The dealership will perform the necessary software update to restore the full functionality of your Audi e-tron GT HUD navigation display.

---

Source: NHTSA ID: 10212153
