2022 Audi e-tron GT HUD Navigation Not Displayed TSB

Owners of 2022 Audi e-tron GT and RS e-tron GT vehicles may notice that navigation directions are not appearing on their Head-Up Display (HUD). Audi has released Technical Service Bulletin (TSB) PSS 90, also identified as 90 22 49 2065815/2, to address this specific concern. This TSB supersedes a previous bulletin, Group 90 number 22-40, dated January 31, 2022.

Symptoms

The primary symptom reported by customers is that "No navigation map or directions are displayed on the heads-up display (HUD)." It is important to note that all other information, such as speed or warning indicators, continues to display properly on the HUD. This issue specifically impacts the navigation functionality of the 2022 Audi e-tron GT HUD navigation system.

Technical Background

Audi has identified that a software malfunction is the underlying cause for the navigation data not being displayed on the HUD. This indicates that the issue is not due to a hardware failure but rather a problem within the vehicle's electronic systems responsible for projecting navigation information.

Important Warnings for Owners

Audi explicitly states that no repairs are necessary at this point, and owners should not attempt to replace any components for this condition. Replacing parts will not resolve the customer's concern, as the root cause is a software issue that is still under development.

Repair Procedure Summary

As of the TSB's publication on March 7, 2022, a definitive solution for the 2022 Audi e-tron GT HUD navigation issue is still under development. Audi anticipates that a fix will be available by the end of the fourth quarter of 2022. Dealers are instructed to inform customers about the forthcoming solution and to create a Pending Service Solutions (PSS) record in the AccessAudi system. This TSB is informational only and does not currently fall under standard Audi Warranty procedures.

Revision History

The TSB has undergone the following revisions:

• Revision 1 (January 31, 2022): Initial publication.
• Revision 2 (March 7, 2022): Revised service information, including an updated expected release date for the solution, and a corrected header (part number filter).

Owner Action

If you own a 2022 Audi e-tron GT or RS e-tron GT and are experiencing the "No navigation map or directions are displayed on the heads-up display (HUD)" symptom, no immediate action is required beyond being aware of this bulletin. Do not seek replacement of HUD components, as this will not resolve the issue. Audi advises waiting for the software solution, which is expected by the end of Q4 2022. You may wish to contact your authorized Audi dealer to ensure they are aware of your concern and to be notified when the software update becomes available.

Source: NHTSA ID: 10208904
