2023-2024 Audi Q7 Q8 MIL On: DTC P060C00 in ECM

Audi has issued Technical Service Bulletin (TSB) 01 24 19 2072046/4 to address a 'MIL on' condition and the diagnostic trouble code (DTC) P060C00 in certain 2023-2024 Audi Q7 and Q8 vehicles equipped with the 3.0L engine. This TSB specifically targets the Audi Q8 P060C00 issue, which is related to the Engine Control Module (ECM).

This bulletin, dated April 18, 2024, supersedes Technical Service Bulletin Group 01 number 23-05 dated December 15, 2023, and replaces Pending Service Solution (PSS) TSB 2067767.

Symptoms

Owners of affected 2023-2024 Audi Q7 and Q8 vehicles may notice the Malfunction Indicator Lamp (MIL), commonly known as the 'Check Engine Light,' illuminated on their dashboard. This 'MIL on' condition is often accompanied by the storage of DTC P060C00, indicating an 'Internal Control Module Main Processor Performance' issue within the ECM. In some cases, drivers might also observe an 'EPC light on' or "various warnings or poor performance" messages, all stemming from the same underlying Audi Q8 P060C00 fault.

Fault Codes / DTCs

The primary diagnostic trouble code associated with this condition is:

Code	Description	Symptom Code
P060C00	Internal Control Module Main Processor Performance	30924

Technical Background and Diagnosis

Audi has identified that the DTC P060C00 is stored in the Engine Control Module (ECM), specifically the -J623- unit (address word 0001). This is considered a rare occurrence, stemming from the sensitivity of the diagnostic software within the ECM. The software's sensitivity can incorrectly trigger the fault code, leading to the illumination of the MIL.

Repair Procedure Summary

The resolution for the 'MIL on' condition and DTC P060C00 involves updating the software in the Engine Control Module (ECM) -J623- (address word 0001). This is performed using the Software Version Management (SVM) system.

Technicians should follow the instructions outlined in TSB 2011732: 00 Software Version Management (SVM), operating instructions. The SVM action code required for this update is 01A255. The update will install new software versions into the ECM, such as 0002, replacing older versions like 0001.

Required Tools or Parts

To perform the software update, technicians will need:

• VAS 6160/VAS 6150 tester with the current version of ODIS (Windows 10).

Warranty Information

This repair is generally covered under warranty for vehicles within the 110 Up to 48 Months/50,000 Miles period. For Certified Pre-Owned (CPO) vehicles, the claim type is G10, requiring owner verification. If the vehicle is outside of any warranty, this Technical Service Bulletin is for informational purposes only, and repair costs may apply.

• Service Number: 2470
• Damage Code: 0039
• Labor Operations: Software Update (0151 0060), with time stated on the diagnostic protocol (maximum 60 TU).
• Diagnostic Time: Software Update (0151 0010), referring to SRT for associated operations.
• Road tests before and after the service procedure have no allowance (0 TU).
• Claim Comment: As per TSB 2072046/4.

All warranty claims must adhere to the Audi Warranty Policies and Procedures Manual.

Owner Action

If your 2023-2024 Audi Q7 or Q8 is experiencing a 'MIL on' condition or you suspect an Audi Q8 P060C00 fault, it is recommended to contact your authorized Audi dealership. They can diagnose the issue and perform the necessary software update to the Engine Control Module (ECM) as described in TSB 01 24 19 2072046/4.

---

Source: NHTSA ID: 10253740
