2025-2026 Audi A5/A6/S5 Glass Roof Flickers TSB 2079213/3

This Technical Service Bulletin (TSB) 2079213/3, released on January 28, 2026, addresses concerns with the variable glass roof system in certain Audi models. Specifically, it applies to 2026 Audi A6 (model FN), 2025 Audi A6 e-tron (model GH), and 2025-2026 Audi A5 and S5 vehicles. The issue is relevant for all VIN ranges of these models that are equipped with the PR: 3FP glass sunroof featuring electric darkening capabilities.

Revision History

This bulletin has undergone several revisions to expand its scope and update information:

• Revision 3: The current version, which revised the header to include additional models and model years.
• Revision 2 (September 25, 2025): Revised the header to add specific models.
• Revision 1 (September 09, 2025): The initial publication of the bulletin.

Symptoms

Owners of affected Audi vehicles may observe that the variable glass roof flickers erratically. Additionally, the glass roof may become completely inoperable, preventing it from opening, closing, or adjusting as intended. The customer complaint is typically described as: "The variable glass roof flickers or cannot be operated."

No Associated Fault Codes

Unlike many vehicle malfunctions, Audi's workshop findings for this particular issue indicate that there is "No relevant entry in event memory." This means that diagnostic trouble codes (DTCs) are not typically stored in the vehicle's computer system for this specific problem, making diagnosis reliant on physical inspection and symptom reproduction.

Technical Background

Audi has identified two primary technical reasons for the glass roof flickering or inoperability:

1. Incorrectly Plugged Connectors: The connectors on the relevant control unit may not be properly seated or plugged in correctly.
2. Control Unit Deviation: The control unit J1288 may deviate from standard series production specifications.

Production Solution

To address these issues at the manufacturing level, Audi has implemented two solutions:

1. Employee Training: Instructions have been provided to production employees on how to correctly insert the connectors for the glass roof system.
2. Software Optimization: A software optimization for the J1288 control unit is expected to be released in November 2026 to improve its performance and reliability.

Repair Procedure Summary

If a customer complaint regarding the variable glass roof flickering or inoperability can be reproduced, technicians should follow these steps:

1. Lower the Headliner: The vehicle's headliner must be carefully lowered to gain access to the control units.
2. Check Connectors: Inspect all connectors on both control units associated with the glass roof system to ensure they are securely plugged in.
3. Control Unit Replacement: If all connectors are found to be correctly plugged in, and the complaint still persists, the control unit J1288 must be replaced. Figure 1 in the TSB visually highlights the location of control unit J1288 for technicians.

Warranty Information

Repairs performed under TSB 2079213/3 are subject to Audi's warranty policies. The Service Number for this operation is 6065, and the Damage Code is 0040. The following labor operations and associated time units (TU) are specified:

• Loosen and secure roof trim: Labor operation 7084 0900. Refer to the Service Repair Time (SRT) for associated operations.
• Check sliding sunroof adjustment control unit: Labor operation 6065 0199, allocated 10 TU.
• Remove and install sliding sunroof adjustment control unit: Labor operation 6065 1999, allocated 10 TU.
• GFF / Guided Functions: Labor operation 0150 0060, with labor time determined according to the diagnostic log.

Claim comments should reference "As per TSB 2079213/3." All warranty claims must adhere to the Audi Warranty Policies and Procedures Manual and are subject to review by Audi Warranty.

Important Warnings for Owners

Owners should be aware that if their vehicle is outside of its warranty period, this Technical Service Bulletin is for informational purposes only. This means that any diagnostic or repair costs incurred may not be covered by Audi and would be the owner's responsibility.

NHTSA ID: 10200843
