2025 Audi A5/Q5 Reversing Camera Control Unit TSB 2078367/1

Audi has issued Technical Service Bulletin (TSB) 2078367/1, dated June 27, 2025, to address concerns with the reversing camera system control unit J772 and the control unit for the overhead view camera J928. This TSB provides guidance for technicians on replacing these components and ensuring proper functionality in affected vehicles. The Audi reversing camera fault can manifest in several ways, impacting driver assistance and parking aid systems.

This bulletin, referenced as 2078219, is specifically for the United States market and outlines procedures for replacing the control units due to software issues. New part versions require additional start-up steps to ensure compatibility with the vehicle's existing systems.

Important Warning for Technicians

This TSB includes a critical notice for service personnel:

"This TSB only applies and must only be used if you are instructed to refer to it by ETKA. You were instructed to refer to this TSB (or TPI 2078219) by ETKA when replacing reversing camera system control unit -J772- or Peripheral camera system control unit -J928-."

This means that the repair outlined in TSB 2078367/1 should only be performed if specifically directed by the ETKA system during a diagnostic process.

Symptoms of an Audi Reversing Camera Fault

Owners of affected Audi vehicles may notice several issues related to the reversing camera and associated assistance systems. These symptoms are primarily related to the "reverse camera image" and overall functionality of the parking aid, park assist, and rear traffic alert systems. The reported complaint types include:

• "reverse camera image functionality faulty"
• "reverse camera image does not switch on/connect"
• "reverse camera image switches off by itself"
• "reverse camera image misfire"

Additionally, issues with the Software Version Management (SVM) part replacement process may lead to the system's functionality being unable to be started.

Technical Background

According to Audi, the need for this TSB stems from software issues affecting the J772 reversing camera system control unit and the J928 peripheral camera system control unit. Due to these issues, only new part versions of these control units are being supplied. These updated parts require specific additional start-up steps to ensure they are compatible with the vehicle's existing software baseline.

Repair Procedure Summary

To address the Audi reversing camera fault, technicians are instructed to replace the affected control units. The original part numbers (ending in H or N) have been discontinued and are replaced by updated part numbers (ending in P). The repair involves several key steps:

1. Part Replacement: Order and install the new part versions, specifically 85E980568P or 85E907428P, depending on the vehicle model and PR number.
2. Component Activation: Activate the newly installed component using the "Replace control module" test program within the diagnostic system.
3. Field Campaign Check: Check the vehicle for any open field campaigns in ELSA and perform them as necessary.
4. Software Update: After completing the previous steps, perform a software update in accordance with TSB 2077960, if applicable.

This process ensures that the new control units are properly integrated and functioning correctly with the vehicle's systems.

Required Parts

When replacing the J772 or J928 control units, the following updated part numbers are required:

• 85E980568P (replaces 85E980568H and 85E980568N)
• 85E907428P (replaces 85E907428H and 85E907428N)

Warranty Information

Audi states that TSB 2078367/1 is for informational purposes only and is not applicable to any Audi Warranty. Owners should consult with their dealership regarding specific repair costs and warranty coverage for their vehicle.

What Owners Should Know

If you experience an Audi reversing camera fault in your 2025 Audi A5, S5, Q5, or SQ5, it is recommended to schedule a service appointment with an authorized Audi dealership. While the TSB provides repair instructions for technicians, the warranty status indicates that this specific bulletin does not guarantee warranty coverage for the repair. Always refer to your vehicle's warranty terms and discuss any potential costs with your service advisor.

---

Source: NHTSA ID 11020381
