2025 BMW X3 Delivery Stop: Steering Gear Fault

Important Warnings for Owners and Dealers

BMW has issued critical directives regarding vehicles affected by this delivery stop:

• "Do not deliver to a customer a New, Certified Pre-Owned or Used vehicle subject to a Delivery Stop, until the vehicle is repaired."
• "Do not use or sell replacement equipment/parts subject to a Delivery Stop."

This repair, detailed in SIB 32 02 26, is classified as "MOBILE FRIENDLY" and "REMOTE SOFTWARE UPGRADE (RSU) FRIENDLY", indicating flexibility in its execution.

Symptoms of a Faulty Steering Gear

Owners of affected vehicles may notice a "Check Control message" appearing on the instrument cluster. Additionally, they might experience a "minimally changed steering feel" while driving. These symptoms indicate a potential issue with the steering system, which is the 2025 BMW X3 steering gear fault.

The Root Cause

The underlying cause of this issue is identified as a faulty sensor within the steering gear. This sensor is responsible for detecting the driver's steering request, and its malfunction can lead to the observed symptoms and necessitate the delivery stop.

Repair Procedure Summary

The repair for the 2025 BMW X3 steering gear fault involves replacing the entire steering gear assembly. Technicians must follow the specific repair instruction REP32 13 572, titled "Replace electrical steering box (EPS)". A key detail in the procedure notes that during REP Step 20, only the right front-end strut needs to be removed, not the left.

After replacing the steering gear, the procedure also requires:

• Commissioning and initialization of the electromechanical steering gear (EPS).
• Checking the wheel alignment using the Kinematics Diagnosis System, including ride height measurement.
• Adjusting the toe-in on the front axle.

Required Parts and Materials

The following parts and materials are specified for the steering gear replacement, depending on the vehicle's engine variant:

For G45 X3 30 with B48 engine:

• Steering gear, electric without SA 2VL: Part Number 32 10 5 B6C 639
• Steering gear, electric with SA 2VL: Part Number 32 10 5 B6C 640
• Various hardware including star-socket screws (07 11 9 908 587), combination nuts (33 30 6 787 062), Torx bolts (32 30 6 778 609), pipe clamps (32 10 6 791 548), and hex nuts with flange (37 10 6 789 678).

For G45 X3 M50 with B58 engine:

• Steering gear, electric: Part Number 32 10 5 B6C 640
• Various hardware including star-socket screws (07 11 9 908 587, 07 14 7 426 660), combination nuts (33 30 6 787 062), Torx bolts (32 30 6 778 609), multi-purpose bolts (07 14 6 885 922), hex bolts with washer (31 10 6 872 063, 31 10 6 893 509), hexagon screws with flange (07 11 9 904 141), hex nuts with flange (37 10 6 789 678), self-locking collar nuts (33 32 6 760 668), Torx screws (07 14 8 869 310), O-rings (13 64 7 675 557), and hex bolts (07 14 7 483 888).

Bulk Supply Materials:

• Grease FB-1: Part Number 83 23 8 849 305

Additional fluids, lubricants, and one-time use fasteners not explicitly listed above should be selected from the Electronic Parts Catalogue or other approved BMW Group resources as per the specific vehicle type.

Warranty Information and Claim Details

Reimbursement for this action is handled via normal claim entry using Repair Code 0032860300. Various labor operation codes are provided for different scenarios, including replacing the steering gear, programming, and encoding control units. These codes include:

• 00 79 728 and 00 79 729 for “Plusposition” work (vehicle already in for other work).
• 00 79 184 and 00 79 185 for “Main work” (this action is the primary reason for the visit).
• 00 79 730 for additional work adjusting the rear axle if required.
• 00 79 731 and 00 79 186 for vehicles already repaired through another campaign.

The flat rate labor operation codes include commissioning the electromechanical steering gear (EPS), wheel alignment checks, and front axle toe-in adjustment. Sublet Code 4 allows reimbursement for bulk supply materials up to $30.00. Alternative Mobility Solution (AMS) expenses for vehicle owners can also be claimed under a separate sublet code, with further details available in SI B01 29 16.

---

Source: NHTSA ID: 11030334
