2023-2024 Audi A3/S3/RS3 Instrument Cluster 'No Entries Available' TSB

Symptoms

Owners of 2023-2024 Audi A3, S3, and RS3 models may notice that their selected call list and/or media list is only displayed in the instrument cluster for a few seconds. Following this brief display, the list is discarded, and the message “No entries available” appears on the instrument cluster display. This issue indicates a problem with the instrument cluster's ability to properly retrieve and show this information.

Fault Codes / DTCs

When diagnosing this issue, technicians may find the following Diagnostic Trouble Code (DTC) stored in the instrument cluster (J285, address word 0017):

Code	Description	Module	Storage State
U105400	Information electronics control module 1 No communication	Instrument cluster J285	Intermittent

Diagnosis / Trigger Conditions

Workshop findings indicate that the presence of emojis (small symbols or pictograms, such as smileys or everyday objects) within the call or media lists can trigger this fault. The intermittent nature of DTC U105400 further points to a software-related communication problem within the instrument cluster.

Repair Procedure Summary

Audi Technical Service Bulletin (TSB) 2073608/2 outlines a software update as the solution for the "Audi A3 instrument cluster no entries available" problem. The repair involves updating the instrument cluster's software to a newer version.

1. Activate DoIP: Ensure Diagnostic over Internet Protocol (DoIP) is active in ODIS. This is crucial for flashing control modules in supported vehicles.
2. Start Update: Initiate the software update on the workshop tester by selecting "flash" and entering the specified SVM code.
3. Update Instrument Cluster: Update the instrument cluster (diagnostic address 0017) to software version 7391 using SVM code 17A051. Follow all instructions provided by the tester.

Important Warnings

Technicians must adhere to specific procedures for this update. Always use DoIP when flashing a control module via ODIS in supported vehicles. To activate DoIP, select Administration >> General >> GFF Process >> DoIP communication >> Only allow DoIP communication. This setting will automatically reset when the diagnostic session ends. DoIP is active if a red LED is observed on the VAS 6154(A).

Warranty Information

This service bulletin provides specific codes for warranty claims. The Service Number is 9025, and the Damage Code is 0039. Labor operations for the software update include 0151 0010 and 0151 0060. All warranty claims must comply with the Audi Warranty Policies and Procedures Manual, and claims are subject to review or audit by Audi Warranty. If the vehicle is outside of warranty, this Technical Service Bulletin is for informational purposes only.

Revision History

This bulletin, TSB 2073608/2, was initially published on April 5, 2024. It was subsequently revised (Revision 2) to include updated service instructions, SVM codes, and an updated warranty table.

Production Solution

Audi has implemented optimized software in production for model year 2025 vehicles to prevent this issue from occurring in newer models.

NHTSA ID: 11015736
