2021 Audi MMI Map Update Error TSB 2073866/1

Owners of certain 2021 Audi vehicles equipped with the MIB2+ infotainment system may encounter issues when attempting to install online map updates. This problem, identified in Technical Service Bulletin (TSB) 2073866/1, prevents the successful installation of new map data, leading to various error messages displayed on the MMI screen. This can be a frustrating Audi e-tron MMI error that impacts navigation functionality.

Symptoms

When an automatic online map update fails to install successfully, 2021 Audi owners may observe one of the following error messages on their MMI display, either immediately or after a period of time:

• "The update data is not compatible."
• "Error: the update is not possible."
• "An unknown error has occurred. The operation has been cancelled."
• "Please wait ..."
• Or other similar error messages.

Technical Background

The root cause of this map update failure is often corrupt map data residing within the control unit for information electronics, identified as J794. This corruption typically stems from a previous online map update that did not complete correctly.

Important Warnings

Audi has issued specific warnings regarding this service procedure:

• Warranty Coverage: "Map updates outside the scope of the license on the vehicle are not covered under the TSB. Always use a map version that is compatible with the license on the current vehicle."
• Claim Denial: "Claims for map activation documents may be denied by warranty."

Owners should ensure their map updates are within the vehicle's license scope to avoid potential warranty issues.

Repair Procedure Summary

To resolve the Audi e-tron MMI error and successfully update the navigation maps, technicians will perform a multi-step procedure focused on erasing and reinstalling the navigation database. The information electronics control unit (5F) does not require replacement for this issue. The process outlined in TSB 2073866/1 involves:

1. Temporarily deactivating automatic online map updates and saving the change by locking/unlocking the vehicle.
2. Performing a partial reset of factory settings specifically for "online updates" and allowing a bus sleep cycle of at least one hour to complete.
3. Accessing "Self-diagnosis" mode on a diagnostic tester.
4. Selecting diagnostic address 005F (Information electronics 1).
5. Using the "Formatting partitions of internal memory" function within basic settings.
6. Selecting "Navigation database" as the parameter and initiating the basic setting.
7. Exiting the diagnostic session.
8. Allowing another bus sleep cycle and waiting for the MMI boot-up process to complete after restarting.
9. Inserting an SD card containing the most current navigation database into the vehicle's SD card reader.
10. Navigating to "Settings" on the MMI home screen.
11. Opening the "System maintenance" menu.
12. Selecting "Software update," inserting the SD card, and following the on-screen instructions.
13. Performing a "soft reset" of the MMI by pressing the On/Off/Volume/Skip button on the center console for at least 10 seconds.
14. Removing the SD card.
15. Finally, verifying navigation system functionality and reactivating automatic online map updates via the MMI under HOME > Settings > System maintenance.

Required Tools or Parts

This repair requires a diagnostic tester and an SD card loaded with the most current navigation database for the specific vehicle VIN.

Warranty Information

This repair is generally covered under Audi's warranty policies. For vehicles within 48 months or 50,000 miles, Claim Type 110 applies. For Certified Pre-Owned (CPO) vehicles, Claim Type G10 is used after verifying ownership. If the vehicle is outside of warranty, this Technical Service Bulletin serves as informational guidance only. The specific labor operations and times are:

• Program display and operating unit control unit: Labor operation 9196 2599, 20 Time Units (TU).
• Check and adjust display and operating unit control unit: Labor operation 9196 0599, 10 TU.
• Charge battery: Labor operation 2706 8950 (refer to SRT for associated operations).
• Self-diagnosis: Diagnostic time 0129 0000 (refer to SRT for associated operations).
• Road test prior to service: No allowance, 0 TU.
• Road test after service: No allowance, 0 TU.

Claims must be submitted as per TSB 2073866/1 and in accordance with the Audi Warranty Policies and Procedures Manual.

---

Source: NHTSA ID: 11002160
